| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2004 | R3 | 30 | = 3000°K (CRI >80) | 12 | EL | = on/off | L = 56 mm | ||||
| 40 | = 4000°K (CRI >80) | 24 | ES | = on/off | L = 31 mm | ||||||
| 94 | = 4000°K (CRI >90) | 30 | |||||||||
| 36 |
| Download | Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | L (mm) | P (mm) | H (mm) | D (mm) | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2004R34012EL | 12 | - | 4000°K - CRI>80 | on/off (L=56 mm) | 1260 | 105 | 56 | 90 | 565 | - | 0.70 | |
| 2004R34024EL | 24 | - | 4000°K - CRI>80 | on/off (L=56 mm) | 2520 | 105 | 56 | 90 | 1125 | - | 1.5 | |
| 2004R34030EL | 30 | - | 4000°K - CRI>80 | on/off (L=56 mm) | 3150 | 105 | 56 | 90 | 1405 | - | 1.9 | |
| 2004R34036EL | 36 | - | 4000°K - CRI>80 | on/off (L=56 mm) | 3780 | 105 | 56 | 90 | 1685 | - | 2.3 | |
| 2004R34012ES | 12 | - | 4000°K - CRI>80 | on/off (L=31 mm) | 1260 | 105 | 31 | 90 | 565 | - | 0.50 | |
| 2004R34024ES | 24 | - | 4000°K - CRI>80 | on/off (L=31 mm) | 2520 | 105 | 31 | 90 | 1125 | - | 1.0 | |
| 2004R34030ES | 30 | - | 4000°K - CRI>80 | on/off (L=31 mm) | 3150 | 105 | 31 | 90 | 1405 | - | 1.3 | |
| 2004R34036ES | 36 | - | 4000°K - CRI>80 | on/off (L=31 mm) | 3780 | 105 | 31 | 90 | 1685 | - | 1.6 | |
| 2004R33012EL | 12 | - | 3000°K - CRI>80 | on/off (L=56 mm) | 1195 | 100 | 56 | 90 | 565 | - | 0.70 | |
| 2004R33024EL | 24 | - | 3000°K - CRI>80 | on/off (L=56 mm) | 2390 | 100 | 56 | 90 | 1125 | - | 1.5 | |
| 2004R33030EL | 30 | - | 3000°K - CRI>80 | on/off (L=56 mm) | 2988 | 100 | 56 | 90 | 1405 | - | 1.9 | |
| 2004R33036EL | 36 | - | 3000°K - CRI>80 | on/off (L=56 mm) | 3585 | 100 | 56 | 90 | 1685 | - | 2.3 | |
| 2004R33012ES | 12 | - | 3000°K - CRI>80 | on/off (L=31 mm) | 1195 | 100 | 31 | 90 | 565 | - | 0.50 | |
| 2004R33024ES | 24 | - | 3000°K - CRI>80 | on/off (L=31 mm) | 2390 | 100 | 31 | 90 | 1125 | - | 1.0 | |
| 2004R33030ES | 30 | - | 3000°K - CRI>80 | on/off (L=31 mm) | 2988 | 100 | 31 | 90 | 1405 | - | 1.3 | |
| 2004R33036ES | 36 | - | 3000°K - CRI>80 | on/off (L=31 mm) | 3585 | 100 | 31 | 90 | 1685 | - | 1.6 | |
| 2004R39412EL | 12 | - | 4000°K - CRI>90 | on/off (L=56 mm) | 1070 | 89 | 56 | 90 | 565 | - | 0.70 | |
| 2004R39424EL | 24 | - | 4000°K - CRI>90 | on/off (L=56 mm) | 2140 | 89 | 56 | 90 | 1125 | - | 1.5 | |
| 2004R39430EL | 30 | - | 4000°K - CRI>90 | on/off (L=56 mm) | 2675 | 89 | 56 | 90 | 1405 | - | 1.9 | |
| 2004R39436EL | 36 | - | 4000°K - CRI>90 | on/off (L=56 mm) | 3210 | 89 | 56 | 90 | 1685 | - | 2.3 |
