| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 2102 | S2 | 40 | = 4000°K (CRI >80) | 09 | 30 | EL | = on/off (DIP-switch) | ||||
| 50 | = 5000°K (CRI >80) | 11 | 32 | ES | = on/off (CPSS) | ||||||
| 65 | = 6500°K (CRI >80) | 13 | 36 | LD | = dali 2 / dali 2 push | ||||||
| 16 | 37 | D1 | = dali 2 + em. 1h | ||||||||
| 18 | 40 | E1 | = em. 1h (DIP-switch) | ||||||||
| 19 | 46 | E3 | = em. 3h (DIP-switch) | ||||||||
| 21 | 47 | FC | = through wiring (DIP-switch) | ||||||||
| 23 | 49 | ||||||||||
| 24 | 59 | ||||||||||
| 26 | 62 | ||||||||||
| 27 | 64 | ||||||||||
| 29 | 70 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2102S24009EL | 9 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 1429 | 159 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24011EL | 11 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 1798 | 163 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24013EL | 13 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 2166 | 167 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24016EL | 16 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 2502 | 156 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24018EL | 18 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 2983 | 166 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24019EL | 19 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 3021 | 159 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24021EL | 21 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 3550 | 169 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24023EL | 23 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 3755 | 163 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24024EL | 24 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 3728 | 155 | 62 | 1435 | 62 | - | 1.5 | |
| 2102S24026EL | 26 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 3875 | 149 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24027EL | 27 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 4412 | 163 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24029EL | 29 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 4369 | 151 | 62 | 595 | 62 | - | 0.8 | |
| 2102S24030EL | 30 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 4694 | 156 | 62 | 1435 | 62 | - | 1.5 | |
| 2102S24032EL | 32 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 5222 | 163 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24036EL | 36 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 6037 | 168 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24037EL | 37 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 5650 | 153 | 62 | 1435 | 62 | - | 1.5 | |
| 2102S24040EL | 40 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 6527 | 163 | 62 | 1435 | 62 | - | 1.5 | |
| 2102S24046EL | 46 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 7409 | 161 | 62 | 1155 | 62 | - | 1.3 | |
| 2102S24047EL | 47 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 8285 | 176 | 62 | 1435 | 62 | - | 1.5 | |
| 2102S24049EL | 49 | - | 4000°K - CRI>80 | on/off (DIP-switch) | 8567 | 175 | 62 | 1155 | 62 | - | 1.3 |
