| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 2300 | 1S | 27 | = 2700°K (CRI >80) | 07 | GL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 14 | GD | = dali 2 / dali 2 push | ||||||
| 40 | = 4000°K (CRI >80) | |||||||||
| 93 | = 3000°K (CRI >90) | |||||||||
| 94 | = 4000°K (CRI >90) |
| Download | Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | L (mm) | P (mm) | H (mm) | D (mm) | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 23001S4007GL | 7 | - | 4000°K - CRI>80 | on/off | 861 | 123 | 150 | - | 78 | - | 0.80 | |
| 23001S4014GL | 14 | - | 4000°K - CRI>80 | on/off | 1646 | 118 | 150 | - | 78 | - | 0.80 | |
| 23001S4007GD | 7 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 861 | 123 | 150 | - | 78 | - | 0.80 | |
| 23001S4014GD | 14 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 1646 | 118 | 150 | - | 78 | - | 0.80 | |
| 23001S3007GL | 7 | - | 3000°K - CRI>80 | on/off | 817 | 117 | 150 | - | 78 | - | 0.80 | |
| 23001S3014GL | 14 | - | 3000°K - CRI>80 | on/off | 1561 | 112 | 150 | - | 78 | - | 0.80 | |
| 23001S3007GD | 7 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 817 | 117 | 150 | - | 78 | - | 0.80 | |
| 23001S3014GD | 14 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 1561 | 112 | 150 | - | 78 | - | 0.80 | |
| 23001S2707GL | 7 | - | 2700°K - CRI>80 | on/off | 791 | 113 | 150 | - | 78 | - | 0.80 | |
| 23001S2714GL | 14 | - | 2700°K - CRI>80 | on/off | 1513 | 108 | 150 | - | 78 | - | 0.80 | |
| 23001S2707GD | 7 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 791 | 113 | 150 | - | 78 | - | 0.80 | |
| 23001S2714GD | 14 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 1513 | 108 | 150 | - | 78 | - | 0.80 | |
| 23001S9307GL | 7 | - | 3000°K - CRI>90 | on/off | 718 | 103 | 150 | - | 78 | - | 0.80 | |
| 23001S9314GL | 14 | - | 3000°K - CRI>90 | on/off | 1373 | 98 | 150 | - | 78 | - | 0.80 | |
| 23001S9307GD | 7 | - | 3000°K - CRI>90 | dali 2 / dali 2 push | 718 | 103 | 150 | - | 78 | - | 0.80 | |
| 23001S9314GD | 14 | - | 3000°K - CRI>90 | dali 2 / dali 2 push | 1373 | 98 | 150 | - | 78 | - | 0.80 | |
| 23001S9407GL | 7 | - | 4000°K - CRI>90 | on/off | 731 | 104 | 150 | - | 78 | - | 0.80 | |
| 23001S9414GL | 14 | - | 4000°K - CRI>90 | on/off | 1398 | 100 | 150 | - | 78 | - | 0.80 | |
| 23001S9407GD | 7 | - | 4000°K - CRI>90 | dali 2 / dali 2 push | 731 | 104 | 150 | - | 78 | - | 0.80 | |
| 23001S9414GD | 14 | - | 4000°K - CRI>90 | dali 2 / dali 2 push | 1398 | 100 | 150 | - | 78 | - | 0.80 |
