| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 2300 | 4S | 27 | = 2700°K (CRI >80) | 16 | GL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 24 | GD | = dali 2 / dali 2 push | ||||||
| 40 | = 4000°K (CRI >80) | |||||||||
| 93 | = 3000°K (CRI >90) | |||||||||
| 94 | = 4000°K (CRI >90) |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 23004S4016GL | 16 | - | 4000°K - CRI>80 | on/off | 1953 | 122 | 400 | - | 78 | - | 3.7 | |
| 23004S4016GD | 16 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 1953 | 122 | 400 | - | 78 | - | 3.7 | |
| 23004S4024GL | 24 | - | 4000°K - CRI>80 | on/off | 2743 | 114 | 400 | - | 78 | - | 3.7 | |
| 23004S4024GD | 24 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 2743 | 114 | 400 | - | 78 | - | 3.7 | |
| 23004S3016GL | 16 | - | 3000°K - CRI>80 | on/off | 1852 | 116 | 400 | - | 78 | - | 3.7 | |
| 23004S3016GD | 16 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 1852 | 116 | 400 | - | 78 | - | 3.7 | |
| 23004S3024GL | 24 | - | 3000°K - CRI>80 | on/off | 2602 | 108 | 400 | - | 78 | - | 3.7 | |
| 23004S3024GD | 24 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 2602 | 108 | 400 | - | 78 | - | 3.7 | |
| 23004S2716GL | 16 | - | 2700°K - CRI>80 | on/off | 1795 | 112 | 400 | - | 78 | - | 3.7 | |
| 23004S2716GD | 16 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 1795 | 112 | 400 | - | 78 | - | 3.7 | |
| 23004S2724GL | 24 | - | 2700°K - CRI>80 | on/off | 2521 | 105 | 400 | - | 78 | - | 3.7 | |
| 23004S2724GD | 24 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 2521 | 105 | 400 | - | 78 | - | 3.7 | |
| 23004S9316GL | 16 | - | 3000°K - CRI>90 | on/off | 1629 | 102 | 400 | - | 78 | - | 3.7 | |
| 23004S9316GD | 16 | - | 3000°K - CRI>90 | dali 2 / dali 2 push | 1629 | 102 | 400 | - | 78 | - | 3.7 | |
| 23004S9324GL | 24 | - | 3000°K - CRI>90 | on/off | 2288 | 95 | 400 | - | 78 | - | 3.7 | |
| 23004S9324GD | 24 | - | 3000°K - CRI>90 | dali 2 / dali 2 push | 2288 | 95 | 400 | - | 78 | - | 3.7 | |
| 23004S9416GL | 16 | - | 4000°K - CRI>90 | on/off | 1658 | 104 | 400 | - | 78 | - | 3.7 | |
| 23004S9416GD | 16 | - | 4000°K - CRI>90 | dali 2 / dali 2 push | 1658 | 104 | 400 | - | 78 | - | 3.7 | |
| 23004S9424GL | 24 | - | 4000°K - CRI>90 | on/off | 2329 | 97 | 400 | - | 78 | - | 3.7 | |
| 23004S9424GD | 24 | - | 4000°K - CRI>90 | dali 2 / dali 2 push | 2329 | 97 | 400 | - | 78 | - | 3.7 |
