| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 2300 | 5S | 27 | = 2700°K (CRI >80) | 30 | GL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 38 | GD | = dali 2 / dali 2 push | ||||||
| 40 | = 4000°K (CRI >80) | 50 | ||||||||
| 93 | = 3000°K (CRI >90) | |||||||||
| 94 | = 4000°K (CRI >90) |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 23005S4030GL | 30 | - | 4000°K - CRI>80 | on/off | 3238 | 108 | 500 | - | 78 | - | 4.2 | |
| 23005S4038GL | 38 | - | 4000°K - CRI>80 | on/off | 4053 | 107 | 500 | - | 78 | - | 4.2 | |
| 23005S4050GL | 50 | - | 4000°K - CRI>80 | on/off | 5313 | 106 | 500 | - | 78 | - | 4.2 | |
| 23005S4030GD | 30 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 3238 | 108 | 500 | - | 78 | - | 4.2 | |
| 23005S4038GD | 38 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 4053 | 107 | 500 | - | 78 | - | 4.2 | |
| 23005S4050GD | 50 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 5313 | 106 | 500 | - | 78 | - | 4.2 | |
| 23005S3030GL | 30 | - | 3000°K - CRI>80 | on/off | 3071 | 102 | 500 | - | 78 | - | 4.2 | |
| 23005S3038GL | 38 | - | 3000°K - CRI>80 | on/off | 3844 | 101 | 500 | - | 78 | - | 4.2 | |
| 23005S3050GL | 50 | - | 3000°K - CRI>80 | on/off | 5039 | 101 | 500 | - | 78 | - | 4.2 | |
| 23005S3030GD | 30 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 3071 | 102 | 500 | - | 78 | - | 4.2 | |
| 23005S3038GD | 38 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 3844 | 101 | 500 | - | 78 | - | 4.2 | |
| 23005S3050GD | 50 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 5039 | 101 | 500 | - | 78 | - | 4.2 | |
| 23005S2730GL | 30 | - | 2700°K - CRI>80 | on/off | 2976 | 99 | 500 | - | 78 | - | 4.2 | |
| 23005S2738GL | 38 | - | 2700°K - CRI>80 | on/off | 3725 | 98 | 500 | - | 78 | - | 4.2 | |
| 23005S2750GL | 50 | - | 2700°K - CRI>80 | on/off | 4883 | 98 | 500 | - | 78 | - | 4.2 | |
| 23005S2730GD | 30 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 2976 | 99 | 500 | - | 78 | - | 4.2 | |
| 23005S2738GD | 38 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 3725 | 98 | 500 | - | 78 | - | 4.2 | |
| 23005S2750GD | 50 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 4883 | 98 | 500 | - | 78 | - | 4.2 | |
| 23005S9330GL | 30 | - | 3000°K - CRI>90 | on/off | 2701 | 90 | 500 | - | 78 | - | 4.2 | |
| 23005S9338GL | 38 | - | 3000°K - CRI>90 | on/off | 3381 | 89 | 500 | - | 78 | - | 4.2 |
