| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 6017 | RS | 27 | = 2700°K (CRI >80) | 06 | CL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 14 | ||||||||
| 40 | = 4000°K (CRI >80) | |||||||||
| 97 | = 2700°K (CRI >90) | |||||||||
| 93 | = 3000°K (CRI >90) | |||||||||
| 94 | = 4000°K (CRI >90) |
| Download | Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | L (mm) | P (mm) | H (mm) | D (mm) | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 6017RS4006CL | 6 | - | 4000°K - CRI>80 | on/off | 771 | 128 | 140 | - | 190 | - | 0.60 | |
| 6017RS4014CL | 14 | - | 4000°K - CRI>80 | on/off | 1742 | 124 | 140 | - | 190 | - | 0.60 | |
| 6017RS3006CL | 6 | - | 3000°K - CRI>80 | on/off | 748 | 125 | 140 | - | 190 | - | 0.60 | |
| 6017RS3014CL | 14 | - | 3000°K - CRI>80 | on/off | 1689 | 121 | 140 | - | 190 | - | 0.60 | |
| 6017RS2706CL | 6 | - | 2700°K - CRI>80 | on/off | 712 | 119 | 140 | - | 190 | - | 0.60 | |
| 6017RS2714CL | 14 | - | 2700°K - CRI>80 | on/off | 1609 | 115 | 140 | - | 190 | - | 0.60 | |
| 6017RS9306CL | 6 | - | 3000°K - CRI>90 | on/off | 630 | 105 | 140 | - | 190 | - | 0.60 | |
| 6017RS9314CL | 14 | - | 3000°K - CRI>90 | on/off | 1424 | 102 | 140 | - | 190 | - | 0.60 | |
| 6017RS9706CL | 6 | - | 2700°K - CRI>90 | on/off | 598 | 100 | 140 | - | 190 | - | 0.60 | |
| 6017RS9714CL | 14 | - | 2700°K - CRI>90 | on/off | 1351 | 97 | 140 | - | 190 | - | 0.60 | |
| 6017RS9406CL | 6 | - | 4000°K - CRI>90 | on/off | 661 | 110 | 140 | - | 190 | - | 0.60 | |
| 6017RS9414CL | 14 | - | 4000°K - CRI>90 | on/off | 1493 | 107 | 140 | - | 190 | - | 0.60 |
