| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 7027 | CR | 2 | = ambra (CRI >80) | 030 | GL | = on/off | ||||
| 3 | = 3000°K (CRI >80) | 040 | GD | = dali 2 | ||||||
| 4 | = 4000°K (CRI >80) | 050 | GA | = acid-etched glass | ||||||
| 5 | = 5000°K (CRI >80) | 060 | ||||||||
| 070 | ||||||||||
| 080 | ||||||||||
| 090 | ||||||||||
| 100 | ||||||||||
| 120 |
| Download | Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | L (mm) | P (mm) | H (mm) | D (mm) | Kg |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7027CR4030GL | 30 | - | 4000°K - CRI>80 | on/off | 4918 | 164 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4040GL | 40 | - | 4000°K - CRI>80 | on/off | 6432 | 161 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4050GL | 50 | - | 4000°K - CRI>80 | on/off | 7880 | 158 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4060GL | 60 | - | 4000°K - CRI>80 | on/off | 8349 | 139 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4070GL | 70 | - | 4000°K - CRI>80 | on/off | 11156 | 159 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4080GL | 80 | - | 4000°K - CRI>80 | on/off | 12755 | 159 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4090GL | 90 | - | 4000°K - CRI>80 | on/off | 14504 | 161 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4100GL | 100 | - | 4000°K - CRI>80 | on/off | 15772 | 158 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4120GL | 120 | - | 4000°K - CRI>80 | on/off | 17371 | 145 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4030GD | 30 | - | 4000°K - CRI>80 | dali | 4918 | 164 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4040GD | 40 | - | 4000°K - CRI>80 | dali | 6432 | 161 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4050GD | 50 | - | 4000°K - CRI>80 | dali | 7880 | 158 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4060GD | 60 | - | 4000°K - CRI>80 | dali | 8349 | 139 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4070GD | 70 | - | 4000°K - CRI>80 | dali | 11156 | 159 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4080GD | 80 | - | 4000°K - CRI>80 | dali | 12755 | 159 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4090GD | 90 | - | 4000°K - CRI>80 | dali | 14504 | 161 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4100GD | 100 | - | 4000°K - CRI>80 | dali | 15772 | 158 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4120GD | 120 | - | 4000°K - CRI>80 | dali | 17371 | 145 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4030GA | 30 | - | 4000°K - CRI>80 | acid-etched glass | 4918 | 164 | 205 | 50 | 365 | - | 3.7 | |
| 7027CR4040GA | 40 | - | 4000°K - CRI>80 | acid-etched glass | 6432 | 161 | 205 | 50 | 365 | - | 3.7 |
