| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 7038 | M6 | 2 | = ambra (CRI >80) | 030 | 105 | GL | = on/off | ||||
| 3 | = 3000°K (CRI >80) | 040 | 120 | GD | = dali | ||||||
| 4 | = 4000°K (CRI >80) | 050 | 125 | GA | = acid-etched glass | ||||||
| 5 | = 5000°K (CRI >80) | 054 | 130 | ||||||||
| 6 | = 6500°K (CRI >80) | 068 | 135 | ||||||||
| 073 | 150 | ||||||||||
| 080 | 175 | ||||||||||
| 085 | 190 | ||||||||||
| 100 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7038M64030GL | 30 | 4000°K - CRI>80 | on/off | 5327 | 178 | 295 | 55 | 425 | 5.6 | |||
| 7038M64040GL | 40 | 4000°K - CRI>80 | on/off | 6683 | 167 | 295 | 55 | 425 | 5.6 | |||
| 7038M64050GL | 50 | 4000°K - CRI>80 | on/off | 8339 | 167 | 295 | 55 | 425 | 5.6 | |||
| 7038M64054GL | 54 | 4000°K - CRI>80 | on/off | 8664 | 160 | 295 | 55 | 425 | 5.6 | |||
| 7038M64068GL | 68 | 4000°K - CRI>80 | on/off | 10894 | 160 | 295 | 55 | 425 | 5.6 | |||
| 7038M64073GL | 73 | 4000°K - CRI>80 | on/off | 11515 | 158 | 295 | 55 | 425 | 5.6 | |||
| 7038M64080GL | 80 | 4000°K - CRI>80 | on/off | 12583 | 157 | 295 | 55 | 425 | 5.6 | |||
| 7038M64085GL | 85 | 4000°K - CRI>80 | on/off | 13688 | 161 | 295 | 55 | 425 | 5.6 | |||
| 7038M64100GL | 100 | 4000°K - CRI>80 | on/off | 14794 | 148 | 295 | 55 | 425 | 5.6 | |||
| 7038M64105GL | 105 | 4000°K - CRI>80 | on/off | 16170 | 154 | 295 | 55 | 425 | 5.6 | |||
| 7038M64120GL | 120 | 4000°K - CRI>80 | on/off | 17033 | 142 | 295 | 55 | 425 | 5.6 | |||
| 7038M64125GL | 125 | 4000°K - CRI>80 | on/off | 18759 | 150 | 295 | 55 | 425 | 5.6 | |||
| 7038M64130GL | 130 | 4000°K - CRI>80 | on/off | 17973 | 138 | 295 | 55 | 425 | 5.6 | |||
| 7038M64135GL | 135 | 4000°K - CRI>80 | on/off | 19725 | 146 | 295 | 55 | 425 | 5.6 | |||
| 7038M64150GL | 150 | 4000°K - CRI>80 | on/off | 21611 | 144 | 295 | 55 | 425 | 5.6 | |||
| 7038M64175GL | 175 | 4000°K - CRI>80 | on/off | 24141 | 138 | 295 | 55 | 425 | 5.6 | |||
| 7038M64190GL | 190 | 4000°K - CRI>80 | on/off | 25528 | 134 | 295 | 55 | 425 | 5.6 | |||
| 7038M64030GD | 30 | 4000°K - CRI>80 | dali | 5327 | 178 | 295 | 55 | 425 | 5.6 | |||
| 7038M64040GD | 40 | 4000°K - CRI>80 | dali | 6683 | 167 | 295 | 55 | 425 | 5.6 | |||
| 7038M64050GD | 50 | 4000°K - CRI>80 | dali | 8339 | 167 | 295 | 55 | 425 | 5.6 |
