| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 7054 | MS | 27 | = 2700°K (CRI >80) | 06 | NL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 09 | ||||||||
| 40 | = 4000°K (CRI >80) | 12 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7054MS4006NL | 6 | - | 4000°K - CRI>80 | on/off | 616 | 103 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS4009NL | 9 | - | 4000°K - CRI>80 | on/off | 965 | 107 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS4012NL | 12 | - | 4000°K - CRI>80 | on/off | 1189 | 99 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3006NL | 6 | - | 3000°K - CRI>80 | on/off | 585 | 98 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3009NL | 9 | - | 3000°K - CRI>80 | on/off | 916 | 102 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3012NL | 12 | - | 3000°K - CRI>80 | on/off | 1129 | 94 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2706NL | 6 | - | 2700°K - CRI>80 | on/off | 565 | 94 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2709NL | 9 | - | 2700°K - CRI>80 | on/off | 884 | 98 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2712NL | 12 | - | 2700°K - CRI>80 | on/off | 1090 | 91 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS4006ND | 6 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 616 | 103 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS4009ND | 9 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 965 | 107 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS4012ND | 12 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 1189 | 99 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3006ND | 6 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 585 | 98 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3009ND | 9 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 916 | 102 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS3012ND | 12 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 1129 | 94 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2706ND | 6 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 565 | 94 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2709ND | 9 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 884 | 98 | 180 | 112 | 70 | - | 0.95 | |
| 7054MS2712ND | 12 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 1090 | 91 | 180 | 112 | 70 | - | 0.95 |
