| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 7056 | B3 | 27 | = 2700°K (CRI >80) | 20 | GL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 30 | GD | = dali 2 | ||||||
| 40 | = 4000°K (CRI >80) | 40 | ||||||||
| 60 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7056B34020GL | 20 | - | 4000°K - CRI>80 | on/off | 2464 | 123 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34030GL | 30 | - | 4000°K - CRI>80 | on/off | 3644 | 121 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34040GL | 40 | - | 4000°K - CRI>80 | on/off | 4409 | 110 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34060GL | 60 | - | 4000°K - CRI>80 | on/off | 6245 | 104 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34020GD | 20 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 2464 | 123 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34030GD | 30 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 3644 | 121 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34040GD | 40 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 4409 | 110 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B34060GD | 60 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 6245 | 104 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33020GL | 20 | - | 3000°K - CRI>80 | on/off | 2346 | 117 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33030GL | 30 | - | 3000°K - CRI>80 | on/off | 3470 | 116 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33040GL | 40 | - | 3000°K - CRI>80 | on/off | 4198 | 105 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33060GL | 60 | - | 3000°K - CRI>80 | on/off | 5946 | 99 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33020GD | 20 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 2346 | 117 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33030GD | 30 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 3470 | 116 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33040GD | 40 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 4198 | 105 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B33060GD | 60 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 5946 | 99 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B32720GL | 20 | - | 2700°K - CRI>80 | on/off | 2233 | 112 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B32730GL | 30 | - | 2700°K - CRI>80 | on/off | 3302 | 110 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B32740GL | 40 | - | 2700°K - CRI>80 | on/off | 3995 | 100 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B32760GL | 60 | - | 2700°K - CRI>80 | on/off | 5659 | 94 | 105 | 105 | 273 | 165 | 2.5 |
