| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 7056 | B6 | 27 | = 2700°K (CRI >80) | 20 | CL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 30 | CD | = dali 2 | ||||||
| 40 | = 4000°K (CRI >80) | 40 | ||||||||
| 60 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7056B64020CL | 20 | - | 4000°K - CRI>80 | on/off | 2610 | 130 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64030CL | 30 | - | 4000°K - CRI>80 | on/off | 3860 | 129 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64040CL | 40 | - | 4000°K - CRI>80 | on/off | 4670 | 117 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64060CL | 60 | - | 4000°K - CRI>80 | on/off | 6615 | 110 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64020CD | 20 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 2610 | 130 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64030CD | 30 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 3860 | 129 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64040CD | 40 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 4670 | 117 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B64060CD | 60 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 6615 | 110 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63020CL | 20 | - | 3000°K - CRI>80 | on/off | 2485 | 124 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63030CL | 30 | - | 3000°K - CRI>80 | on/off | 3675 | 123 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63040CL | 40 | - | 3000°K - CRI>80 | on/off | 4447 | 111 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63060CL | 60 | - | 3000°K - CRI>80 | on/off | 6299 | 105 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63020CD | 20 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 2485 | 124 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63030CD | 30 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 3675 | 123 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63040CD | 40 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 4447 | 111 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B63060CD | 60 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 6299 | 105 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B62720CL | 20 | - | 2700°K - CRI>80 | on/off | 2365 | 118 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B62730CL | 30 | - | 2700°K - CRI>80 | on/off | 3498 | 117 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B62740CL | 40 | - | 2700°K - CRI>80 | on/off | 4231 | 106 | 105 | 105 | 273 | 165 | 2.5 | |
| 7056B62760CL | 60 | - | 2700°K - CRI>80 | on/off | 5994 | 100 | 105 | 105 | 273 | 165 | 2.5 |
