MAGIC 3/AR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 3 - 7103, Floodlights, art. 7103 Magic 3
Models: 126
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7103AR4= 4000°K (CRI >70)600=600WGL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)820=820WGD= dali (converter)
R= 5700°K (CRI >90)900=900WG4= input 400Vac
100=1000WGX= 1-10v + dmx
120=1200WMG= virtual midnight
135=1350W
144=1440W

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7103AR4600GL600-4000°K - CRI>70on/off101214172655350740-30.5
7103AR4820GL820-4000°K - CRI>70on/off131075163655350740-30.5
7103AR4900GL900-4000°K - CRI>70on/off143136162655350740-30.5
7103AR4100GL1000-4000°K - CRI>70on/off157773161655350740-30.5
7103AR4120GL1200-4000°K - CRI>70on/off178802152655350740-30.5
7103AR4135GL1350-4000°K - CRI>70on/off198688150655350740-30.5
7103AR4144GL1440-4000°K - CRI>70on/off205059145655350740-30.5
7103AR4600GM600-4000°K - CRI>701-10v101214172655350740-30.5
7103AR4820GM820-4000°K - CRI>701-10v131075163655350740-30.5
7103AR4900GM900-4000°K - CRI>701-10v143136162655350740-30.5
7103AR4100GM1000-4000°K - CRI>701-10v157773161655350740-30.5
7103AR4120GM1200-4000°K - CRI>701-10v178802152655350740-30.5
7103AR4135GM1350-4000°K - CRI>701-10v198688150655350740-30.5
7103AR4144GM1440-4000°K - CRI>701-10v205059145655350740-30.5
7103AR4600GD600-4000°K - CRI>70dali101214172655350740-30.5
7103AR4820GD820-4000°K - CRI>70dali131075163655350740-30.5
7103AR4900GD900-4000°K - CRI>70dali143136162655350740-30.5
7103AR4100GD1000-4000°K - CRI>70dali157773161655350740-30.5
7103AR4120GD1200-4000°K - CRI>70dali178802152655350740-30.5
7103AR4135GD1350-4000°K - CRI>70dali198688150655350740-30.5

Accessories
