MAGIC 3/TR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 3 - 7103, Floodlights, art. 7103 Magic 3
Models: 108
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7103TR4= 4000°K (CRI >70)600=600WGL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)820=820WGD= dali (converter)
R= 5700°K (CRI >90)900=900WG4= input 400Vac
100=1000WGX= 1-10v + dmx
120=1200WMG= virtual midnight
135=1350W
144=1440W

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7103TR4600GL600-4000°K - CRI>70on/off101577172655350740-30.5
7103TR4820GL820-4000°K - CRI>70on/off131547163655350740-30.5
7103TR4900GL900-4000°K - CRI>70on/off143650162655350740-30.5
7103TR4100GL1000-4000°K - CRI>70on/off158340161655350740-30.5
7103TR4120GL1200-4000°K - CRI>70on/off179445152655350740-30.5
7103TR4135GL1350-4000°K - CRI>70on/off199403150655350740-30.5
7103TR4600GM600-4000°K - CRI>701-10v101577172655350740-30.5
7103TR4820GM820-4000°K - CRI>701-10v131547163655350740-30.5
7103TR4900GM900-4000°K - CRI>701-10v143650162655350740-30.5
7103TR4100GM1000-4000°K - CRI>701-10v158340161655350740-30.5
7103TR4120GM1200-4000°K - CRI>701-10v179445152655350740-30.5
7103TR4135GM1350-4000°K - CRI>701-10v199403150655350740-30.5
7103TR4600GD600-4000°K - CRI>70dali101577172655350740-30.5
7103TR4820GD820-4000°K - CRI>70dali131547163655350740-30.5
7103TR4900GD900-4000°K - CRI>70dali143650162655350740-30.5
7103TR4100GD1000-4000°K - CRI>70dali158340161655350740-30.5
7103TR4120GD1200-4000°K - CRI>70dali179445152655350740-30.5
7103TR4135GD1350-4000°K - CRI>70dali199403150655350740-30.5
7103TR4600G4600-4000°K - CRI>70input 400Vac101577172655350740-30.5
7103TR4820G4820-4000°K - CRI>70input 400Vac131547163655350740-30.5

Accessories
