MAGIC 4/AR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 4 - 7104, Floodlights, art. 7104 Magic 4
Models: 96
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7104AR4= 4000°K (CRI >70)120=1200WGL= on/off (remote driver)
7= 5700°K (CRI >70)150=1500WGM= 1-10v
R= 5700°K (CRI >90)160=1600WGD= dali
180=1800WG4= input 400Vac
GX= 1-10v + dmx
MG= virtual midnight

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7104AR4120GL1200-4000°K - CRI>70on/off190848162655350980-45.5
7104AR4150GL1500-4000°K - CRI>70on/off229230156655350980-45.5
7104AR4160GL1600-4000°K - CRI>70on/off238403152655350980-45.5
7104AR4180GL1800-4000°K - CRI>70on/off264918150655350980-45.5
7104AR4120GM1200-4000°K - CRI>701-10v190848162655350980-45.5
7104AR4150GM1500-4000°K - CRI>701-10v229230156655350980-45.5
7104AR4160GM1600-4000°K - CRI>701-10v238403152655350980-45.5
7104AR4180GM1800-4000°K - CRI>701-10v264918150655350980-45.5
7104AR4120GD1200-4000°K - CRI>70dali190848162655350980-45.5
7104AR4150GD1500-4000°K - CRI>70dali229230156655350980-45.5
7104AR4160GD1600-4000°K - CRI>70dali238403152655350980-45.5
7104AR4180GD1800-4000°K - CRI>70dali264918150655350980-45.5
7104AR4120G41200-4000°K - CRI>70input 400Vac190848162655350980-45.5
7104AR4150G41500-4000°K - CRI>70input 400Vac229230156655350980-45.5
7104AR4160G41600-4000°K - CRI>70input 400Vac238403152655350980-45.5
7104AR4180G41800-4000°K - CRI>70input 400Vac264918150655350980-45.5
7104AR4120GX1200-4000°K - CRI>701-10v + dmx190848162655350980-45.5
7104AR4150GX1500-4000°K - CRI>701-10v + dmx229230156655350980-45.5
7104AR4160GX1600-4000°K - CRI>701-10v + dmx238403152655350980-45.5
7104AR4180GX1800-4000°K - CRI>701-10v + dmx264918150655350980-45.5

Accessories
