art-7104-magic-4-mr-cr-sr-tr-ar-rr

MAGIC 4/RR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 4 - 7104, Floodlights, art. 7104 Magic 4
Models: 96
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7104RR4= 4000°K (CRI >70)120=1200WGL= on/off (remote driver)
7= 5700°K (CRI >70)150=1500WGM= 1-10v
R= 5700°K (CRI >90)160=1600WGD= dali
180=1800WG4= input 400Vac
GX= 1-10v + dmx
MG= virtual midnight

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7104RRT120GL1200-5700°K - CRI>80on/off168996141655350980-45.5
7104RRT150GL1500-5700°K - CRI>80on/off202983135655350980-45.5
7104RRT160GL1600-5700°K - CRI>80on/off211106132655350980-45.5
7104RRT180GL1800-5700°K - CRI>80on/off234584130655350980-45.5
7104RRT120GM1200-5700°K - CRI>801-10v168996141655350980-45.5
7104RRT150GM1500-5700°K - CRI>801-10v202983135655350980-45.5
7104RRT160GM1600-5700°K - CRI>801-10v211106132655350980-45.5
7104RRT180GM1800-5700°K - CRI>801-10v234584130655350980-45.5
7104RRT120GD1200-5700°K - CRI>80dali168996141655350980-45.5
7104RRT150GD1500-5700°K - CRI>80dali202983135655350980-45.5
7104RRT160GD1600-5700°K - CRI>80dali211106132655350980-45.5
7104RRT180GD1800-5700°K - CRI>80dali234584130655350980-45.5
7104RRT120G41200-5700°K - CRI>80input 400Vac168996141655350980-45.5
7104RRT150G41500-5700°K - CRI>80input 400Vac202983135655350980-45.5
7104RRT160G41600-5700°K - CRI>80input 400Vac211106132655350980-45.5
7104RRT180G41800-5700°K - CRI>80input 400Vac234584130655350980-45.5
7104RRT120GX1200-5700°K - CRI>801-10v + dmx168996141655350980-45.5
7104RRT150GX1500-5700°K - CRI>801-10v + dmx202983135655350980-45.5
7104RRT160GX1600-5700°K - CRI>801-10v + dmx211106132655350980-45.5
7104RRT180GX1800-5700°K - CRI>801-10v + dmx234584130655350980-45.5

Accessories
