MAGIC 4/SR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 4 - 7104, Floodlights, art. 7104 Magic 4
Models: 96
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7104SR4= 4000°K (CRI >70)120=1200WGL= on/off (remote driver)
7= 5700°K (CRI >70)150=1500WGM= 1-10v
R= 5700°K (CRI >90)160=1600WGD= dali
180=1800WG4= input 400Vac
GX= 1-10v + dmx
MG= virtual midnight

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7104SRT120GL1200-5700°K - CRI>80on/off170013142655350980-45.5
7104SRT150GL1500-5700°K - CRI>80on/off204205136655350980-45.5
7104SRT160GL1600-5700°K - CRI>80on/off212378133655350980-45.5
7104SRT180GL1800-5700°K - CRI>80on/off235998131655350980-45.5
7104SRT120GM1200-5700°K - CRI>801-10v170013142655350980-45.5
7104SRT150GM1500-5700°K - CRI>801-10v204205136655350980-45.5
7104SRT160GM1600-5700°K - CRI>801-10v212378133655350980-45.5
7104SRT180GM1800-5700°K - CRI>801-10v235998131655350980-45.5
7104SRT120GD1200-5700°K - CRI>80dali170013142655350980-45.5
7104SRT150GD1500-5700°K - CRI>80dali204205136655350980-45.5
7104SRT160GD1600-5700°K - CRI>80dali212378133655350980-45.5
7104SRT180GD1800-5700°K - CRI>80dali235998131655350980-45.5
7104SRT120G41200-5700°K - CRI>80input 400Vac170013142655350980-45.5
7104SRT150G41500-5700°K - CRI>80input 400Vac204205136655350980-45.5
7104SRT160G41600-5700°K - CRI>80input 400Vac212378133655350980-45.5
7104SRT180G41800-5700°K - CRI>80input 400Vac235998131655350980-45.5
7104SRT120GX1200-5700°K - CRI>801-10v + dmx170013142655350980-45.5
7104SRT150GX1500-5700°K - CRI>801-10v + dmx204205136655350980-45.5
7104SRT160GX1600-5700°K - CRI>801-10v + dmx212378133655350980-45.5
7104SRT180GX1800-5700°K - CRI>801-10v + dmx235998131655350980-45.5

Accessories
