art-7104-magic-4-mr-cr-sr-tr-ar-rr

MAGIC 4/TR

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Die cast aluminium body, coated with polyester anticorrosion powder, silver color, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, MAGIC 4 - 7104, Floodlights, art. 7104 Magic 4
Models: 96
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7104TR4= 4000°K (CRI >70)120=1200WGL= on/off (remote driver)
7= 5700°K (CRI >70)150=1500WGM= 1-10v
R= 5700°K (CRI >90)160=1600WGD= dali
180=1800WG4= input 400Vac
GX= 1-10v + dmx
MG= virtual midnight

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7104TRT120GL1200-5700°K - CRI>80on/off170523142655350980-45.5
7104TRT150GL1500-5700°K - CRI>80on/off204817137655350980-45.5
7104TRT160GL1600-5700°K - CRI>80on/off213013133655350980-45.5
7104TRT180GL1800-5700°K - CRI>80on/off236704132655350980-45.5
7104TRT120GM1200-5700°K - CRI>801-10v170523142655350980-45.5
7104TRT150GM1500-5700°K - CRI>801-10v204817137655350980-45.5
7104TRT160GM1600-5700°K - CRI>801-10v213013133655350980-45.5
7104TRT180GM1800-5700°K - CRI>801-10v236704132655350980-45.5
7104TRT120GD1200-5700°K - CRI>80dali170523142655350980-45.5
7104TRT150GD1500-5700°K - CRI>80dali204817137655350980-45.5
7104TRT160GD1600-5700°K - CRI>80dali213013133655350980-45.5
7104TRT180GD1800-5700°K - CRI>80dali236704132655350980-45.5
7104TRT120G41200-5700°K - CRI>80input 400Vac170523142655350980-45.5
7104TRT150G41500-5700°K - CRI>80input 400Vac204817137655350980-45.5
7104TRT160G41600-5700°K - CRI>80input 400Vac213013133655350980-45.5
7104TRT180G41800-5700°K - CRI>80input 400Vac236704132655350980-45.5
7104TRT120GX1200-5700°K - CRI>801-10v + dmx170523142655350980-45.5
7104TRT150GX1500-5700°K - CRI>801-10v + dmx204817137655350980-45.5
7104TRT160GX1600-5700°K - CRI>801-10v + dmx213013133655350980-45.5
7104TRT180GX1800-5700°K - CRI>801-10v + dmx236704132655350980-45.5

Accessories

TEC-MAR is aimed at constant research and development of new technologies, quality materials, enhanced production processes, in accordance with latest trends in design and technology.
