art.-7105-galaxy-1-a4-a5-a6-s1-c3-m6

GALAXY 1/C3

Indoor and outdoor LED projector for lighting large areas and sports facilities, suitable for ground, wall, or light tower installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder coating silver color. Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Available in six types of opticswith high-performance PMMA lenses: 40° wide-beam asymmetric optics, 65° wide-beam asymmetric optics, 65° narrow-beam asymmetric optics, 10° concentrating symmetric optics, 28° concentrating symmetric optics and 56° symmetric optics.
Categories: Led, art. 7105 Galaxy 1, Floodlights, art. 7105 Galaxy 1
Models: 72
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7105C34= 4000°K (CRI >70)300GL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)320GD= dali (converter)
R= 5700°K (CRI >90)340G4= one 4 all (400v - dali2 - d4i - dmx)
380
410
450
480
540

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7105C34300GL300-4000°K - CRI>70on/off51639174648190290-9.8
7105C34320GL320-4000°K - CRI>70on/off53911170648190290-9.8
7105C34340GL340-4000°K - CRI>70on/off57301170648190290-9.8
7105C34380GL380-4000°K - CRI>70on/off62901167648190290-9.8
7105C34410GL410-4000°K - CRI>70on/off67341166648190290-9.8
7105C34450GL450-4000°K - CRI>70on/off73390165648190290-9.8
7105C34480GL480-4000°K - CRI>70on/off76119160648190290-9.8
7105C34540GL540-4000°K - CRI>70on/off83158167648190290-9.8
7105C34300GD300-4000°K - CRI>70dali converted51639174648190290-9.8
7105C34320GD320-4000°K - CRI>70dali converted53911170648190290-9.8
7105C34340GD340-4000°K - CRI>70dali converted57301170648190290-9.8
7105C34380GD380-4000°K - CRI>70dali converted62901167648190290-9.8
7105C34410GD410-4000°K - CRI>70dali converted67341166648190290-9.8
7105C34450GD450-4000°K - CRI>70dali converted73390165648190290-9.8
7105C34480GD480-4000°K - CRI>70dali converted76119160648190290-9.8
7105C34540GD540-4000°K - CRI>70dali converted83158167648190290-9.8
7105C34300G4300-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)51639174648190290-9.8
7105C34320G4320-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)53911170648190290-9.8
7105C34340G4340-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)57301170648190290-9.8
7105C34380G4380-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)62901167648190290-9.8

Accessories
