GALAXY 1/M6

Indoor and outdoor LED projector for lighting large areas and sports facilities, suitable for ground, wall, or light tower installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder coating silver color. Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Available in six types of opticswith high-performance PMMA lenses: 40° wide-beam asymmetric optics, 65° wide-beam asymmetric optics, 65° narrow-beam asymmetric optics, 10° concentrating symmetric optics, 28° concentrating symmetric optics and 56° symmetric optics.
Categories: Led, GALAXY 1 - 7105, art. 7105 Galaxy 1, Floodlights, art. 7105 Galaxy 1
Models: 72
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7105M64= 4000°K (CRI >70)300GL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)320GD= dali (converter)
R= 5700°K (CRI >90)340G4= one 4 all (400v - dali2 - d4i - dmx)
380
410
450
480
540

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7105M64300GL300-4000°K - CRI>70on/off49817167648190290-9.8
7105M64320GL320-4000°K - CRI>70on/off52009164648190290-9.8
7105M64340GL340-4000°K - CRI>70on/off55278164648190290-9.8
7105M64380GL380-4000°K - CRI>70on/off60681161648190290-9.8
7105M64410GL410-4000°K - CRI>70on/off64964160648190290-9.8
7105M64450GL450-4000°K - CRI>70on/off70800159648190290-9.8
7105M64480GL480-4000°K - CRI>70on/off73432154648190290-9.8
7105M64540GL540-4000°K - CRI>70on/off80223161648190290-9.8
7105M64300GD300-4000°K - CRI>70dali converted49817167648190290-9.8
7105M64320GD320-4000°K - CRI>70dali converted52009164648190290-9.8
7105M64340GD340-4000°K - CRI>70dali converted55278164648190290-9.8
7105M64380GD380-4000°K - CRI>70dali converted60681161648190290-9.8
7105M64410GD410-4000°K - CRI>70dali converted64964160648190290-9.8
7105M64450GD450-4000°K - CRI>70dali converted70800159648190290-9.8
7105M64480GD480-4000°K - CRI>70dali converted73432154648190290-9.8
7105M64540GD540-4000°K - CRI>70dali converted80223161648190290-9.8
7105M64300G4300-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)49817167648190290-9.8
7105M64320G4320-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)52009164648190290-9.8
7105M64340G4340-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)55278164648190290-9.8
7105M64380G4380-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)60681161648190290-9.8
