GALAXY 3/C3

Indoor and outdoor LED projector for lighting large areas and sports facilities, suitable for ground, wall, or light tower installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder coating silver color. Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Available in six types of opticswith high-performance PMMA lenses: 40° wide-beam asymmetric optics, 65° wide-beam asymmetric optics, 65° narrow-beam asymmetric optics, 10° concentrating symmetric optics, 28° concentrating symmetric optics and 56° symmetric optics.
Categories: Led, GALAXY 3 - 7107, art. 7107 Galaxy 3, Floodlights, art. 7107 Galaxy 3
Models: 81
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7107C34= 4000°K (CRI >70)600= 600WGL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)820= 820WGD= dali (converter)
R= 5700°K (CRI >90)900= 900WG4= one 4 all (400v - dali2 - d4i - dmx)
100= 1000W
120= 1200W
135= 1350W
144= 1440W
150= 1500W
162= 1620W

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7107C34600GL600-4000°K - CRI>70on/off106280177650170730-30.5
7107C34820GL820-4000°K - CRI>70on/off141192172650170730-30.5
7107C34900GL900-4000°K - CRI>70on/off154918172650170730-30.5
7107C34100GL1000-4000°K - CRI>70on/off168520169650170730-30.5
7107C34120GL1200-4000°K - CRI>70on/off195377163650170730-30.5
7107C34135GL1350-4000°K - CRI>70on/off220170163650170730-30.5
7107C34144GL1440-4000°K - CRI>70on/off228357159650170730-30.5
7107C34150GL1500-4000°K - CRI>70on/off236507158650170730-30.5
7107C34162GL1620-4000°K - CRI>70on/off249474154650170730-30.5
7107C34600GD600-4000°K - CRI>70dali converted106280177650170730-30.5
7107C34820GD820-4000°K - CRI>70dali converted141192172650170730-30.5
7107C34900GD900-4000°K - CRI>70dali converted154918172650170730-30.5
7107C34100GD1000-4000°K - CRI>70dali converted168520169650170730-30.5
7107C34120GD1200-4000°K - CRI>70dali converted195377163650170730-30.5
7107C34135GD1350-4000°K - CRI>70dali converted220170163650170730-30.5
7107C34144GD1440-4000°K - CRI>70dali converted228357159650170730-30.5
7107C34150GD1500-4000°K - CRI>70dali converted236507158650170730-30.5
7107C34162GD1620-4000°K - CRI>70dali converted249474154650170730-30.5
7107C34600G4600-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)106280177650170730-30.5
7107C34820G4820-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)141192172650170730-30.5

Accessories
