GALAXY 3/M6

Indoor and outdoor LED projector for lighting large areas and sports facilities, suitable for ground, wall, or light tower installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder coating silver color. Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Available in six types of opticswith high-performance PMMA lenses: 40° wide-beam asymmetric optics, 65° wide-beam asymmetric optics, 65° narrow-beam asymmetric optics, 10° concentrating symmetric optics, 28° concentrating symmetric optics and 56° symmetric optics.
Categories: Led, GALAXY 3 - 7107, art. 7107 Galaxy 3, Floodlights, art. 7107 Galaxy 3
Models: 81
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7107M64= 4000°K (CRI >70)600= 600WGL= on/off / 1-10v (remote driver)
7= 5700°K (CRI >70)820= 820WGD= dali (converter)
R= 5700°K (CRI >90)900= 900WG4= one 4 all (400v - dali2 - d4i - dmx)
100= 1000W
120= 1200W
135= 1350W
144= 1440W
150= 1500W
162= 1620W

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7107M64600GL600-4000°K - CRI>70on/off102529171650170730-30.5
7107M64820GL820-4000°K - CRI>70on/off136209166650170730-30.5
7107M64900GL900-4000°K - CRI>70on/off149450166650170730-30.5
7107M64100GL1000-4000°K - CRI>70on/off162572163650170730-30.5
7107M64120GL1200-4000°K - CRI>70on/off188481157650170730-30.5
7107M64135GL1350-4000°K - CRI>70on/off212399157650170730-30.5
7107M64144GL1440-4000°K - CRI>70on/off220297153650170730-30.5
7107M64150GL1500-4000°K - CRI>70on/off228160152650170730-30.5
7107M64162GL1620-4000°K - CRI>70on/off240669149650170730-30.5
7107M64600GD600-4000°K - CRI>70dali converted102529171650170730-30.5
7107M64820GD820-4000°K - CRI>70dali converted136209166650170730-30.5
7107M64900GD900-4000°K - CRI>70dali converted149450166650170730-30.5
7107M64100GD1000-4000°K - CRI>70dali converted162572163650170730-30.5
7107M64120GD1200-4000°K - CRI>70dali converted188481157650170730-30.5
7107M64135GD1350-4000°K - CRI>70dali converted212399157650170730-30.5
7107M64144GD1440-4000°K - CRI>70dali converted220297153650170730-30.5
7107M64150GD1500-4000°K - CRI>70dali converted228160152650170730-30.5
7107M64162GD1620-4000°K - CRI>70dali converted240669149650170730-30.5
7107M64600G4600-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)102529171650170730-30.5
7107M64820G4820-4000°K - CRI>70one 4 all (400V - DALI2 - D4I - DMX)136209166650170730-30.5

Accessories
