BEST 3R RGBW | Mod. EL

30°/60° elliptical beam

Led floodlight for indoor and outdoor use. Suitable for ground, wall, pole or ceiling installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder in silver, Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Elliptical 30°/60° beam.

Categories: Led, BEST 3R RGBW, BEST 3R RGBW, BEST 3R RGBW, Floodlights

Models: 10

Color: Silver

Catalogue abstract

Installation instructions

Legenda

Art.	Mod.	°K (CRI)		W tot.	Options
7233	EL	R	= red	100	GL	= on/off
		G	= green	150	GD	= dali 2
		B	= blue		GR	= remote control
		W	= white		GG	= external gateway
		X	= RGBW

Models

Codice	W tot.	mA	°K - CRI	Options	Lumen OUTPUT	Lm/W	L (mm)	P (mm)	H (mm)	D (mm)	Kg
7233ELR100GL	100	-	4000°K - CRI ≥80	on/off	3928	39	250	60	379	-	3.15
7233ELG100GL	100	-	4000°K - CRI ≥80	on/off	7524	75	250	60	379	-	3.15
7233ELB100GL	100	-	4000°K - CRI ≥80	on/off	2395	24	250	60	379	-	3.15
7233ELW100GL	100	-	4000°K - CRI ≥80	on/off	11846	118	250	60	379	-	3.15
7233ELR100GD	100	-	4000°K - CRI ≥80	dali 2	3928	39	250	60	379	-	3.15
7233ELG100GD	100	-	4000°K - CRI ≥80	dali 2	7524	75	250	60	379	-	3.15
7233ELB100GD	100	-	4000°K - CRI ≥80	dali 2	2395	24	250	60	379	-	3.15
7233ELW100GD	100	-	4000°K - CRI ≥80	dali 2	11846	118	250	60	379	-	3.15
7233ELX150GR	150	-	RGBW	remote control	5816	39	250	60	379	-	3.15
7233ELX150GG	150	-	RGBW	external gateway	5816	39	250	60	379	-	3.15
