| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 8056 | A5 | 3 | = 3000°K (CRI >70) | 275 | GL | = on/off | ||||
| 4 | = 4000°K (CRI >70) | 300 | GM | = 1-10v | ||||||
| 5 | = 5000°K (CRI >70) | 340 | GD | = dali | ||||||
| 7 | = 5700°K (CRI >70) | 380 | G4 | = input 400Vac | ||||||
| R | = 5700°K (CRI >90) | 410 | GX | = 1-10v + dmx | ||||||
| 450 | MG | = virtual midnight |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8056A54275GL | 275 | 4000°K - CRI>70 | on/off | 43061 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056A54300GL | 300 | 4000°K - CRI>70 | on/off | 46352 | 155 | 615 | 240 | 120 | 9.5 | |||
| 8056A54340GL | 340 | 4000°K - CRI>70 | on/off | 54173 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54380GL | 380 | 4000°K - CRI>70 | on/off | 58147 | 153 | 615 | 240 | 120 | 9.5 | |||
| 8056A54410GL | 410 | 4000°K - CRI>70 | on/off | 65048 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54450GL | 450 | 4000°K - CRI>70 | on/off | 68086 | 151 | 615 | 240 | 120 | 9.5 | |||
| 8056A54275GM | 275 | 4000°K - CRI>70 | 1-10v | 43061 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056A54300GM | 300 | 4000°K - CRI>70 | 1-10v | 46352 | 155 | 615 | 240 | 120 | 9.5 | |||
| 8056A54340GM | 340 | 4000°K - CRI>70 | 1-10v | 54173 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54380GM | 380 | 4000°K - CRI>70 | 1-10v | 58147 | 153 | 615 | 240 | 120 | 9.5 | |||
| 8056A54410GM | 410 | 4000°K - CRI>70 | 1-10v | 65048 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54450GM | 450 | 4000°K - CRI>70 | 1-10v | 68086 | 151 | 615 | 240 | 120 | 9.5 | |||
| 8056A54275GD | 275 | 4000°K - CRI>70 | dali | 43061 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056A54300GD | 300 | 4000°K - CRI>70 | dali | 46352 | 155 | 615 | 240 | 120 | 9.5 | |||
| 8056A54340GD | 340 | 4000°K - CRI>70 | dali | 54173 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54380GD | 380 | 4000°K - CRI>70 | dali | 58147 | 153 | 615 | 240 | 120 | 9.5 | |||
| 8056A54410GD | 410 | 4000°K - CRI>70 | dali | 65048 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056A54450GD | 450 | 4000°K - CRI>70 | dali | 68086 | 151 | 615 | 240 | 120 | 9.5 | |||
| 8056A54275G4 | 275 | 4000°K - CRI>70 | input 400Vac | 43061 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056A54300G4 | 300 | 4000°K - CRI>70 | input 400Vac | 46352 | 155 | 615 | 240 | 120 | 9.5 |
