COSMIC 1/M6

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Silver Extruded oxidate aluminium body, zinc-coated and painted bracket, 4 mm thick tempered transparent glass, silicon gasket, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, COSMIC 1 - 8056, Floodlights, art. 8056 Cosmic 1
Models: 180
Color: Silver
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
8056M63= 3000°K (CRI >70)275GL= on/off
4= 4000°K (CRI >70)300GM= 1-10v
5= 5000°K (CRI >70)340GD= dali
7= 5700°K (CRI >70)380G4= input 400Vac
R= 5700°K (CRI >90)410GX= 1-10v + dmx
450MG= virtual midnight

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
8056M64275GL275-4000°K - CRI>70on/off49178180615240120-9.5
8056M64300GL300-4000°K - CRI>70on/off52972178615240120-9.5
8056M64340GL340-4000°K - CRI>70on/off58500175615240120-9.5
8056M64380GL380-4000°K - CRI>70on/off65212173615240120-9.5
8056M64410GL410-4000°K - CRI>70on/off72833179615240120-9.5
8056M64450GL450-4000°K - CRI>70on/off76555171615240120-9.5
8056M64275GM275-4000°K - CRI>701-10v49178180615240120-9.5
8056M64300GM300-4000°K - CRI>701-10v52972178615240120-9.5
8056M64340GM340-4000°K - CRI>701-10v58500175615240120-9.5
8056M64380GM380-4000°K - CRI>701-10v65212173615240120-9.5
8056M64410GM410-4000°K - CRI>701-10v72833179615240120-9.5
8056M64450GM450-4000°K - CRI>701-10v76555171615240120-9.5
8056M64275GD275-4000°K - CRI>70dali49178180615240120-9.5
8056M64300GD300-4000°K - CRI>70dali52972178615240120-9.5
8056M64340GD340-4000°K - CRI>70dali58500175615240120-9.5
8056M64380GD380-4000°K - CRI>70dali65212173615240120-9.5
8056M64410GD410-4000°K - CRI>70dali72833179615240120-9.5
8056M64450GD450-4000°K - CRI>70dali76555171615240120-9.5
8056M64275G4275-4000°K - CRI>70input 400Vac49178180615240120-9.5
8056M64300G4300-4000°K - CRI>70input 400Vac52972178615240120-9.5

Accessories
