| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 8056 | S1 | 3 | = 3000°K (CRI >70) | 275 | GL | = on/off | ||||
| 4 | = 4000°K (CRI >70) | 300 | GM | = 1-10v | ||||||
| 5 | = 5000°K (CRI >70) | 340 | GD | = dali | ||||||
| 7 | = 5700°K (CRI >70) | 380 | G4 | = input 400Vac | ||||||
| R | = 5700°K (CRI >90) | 410 | GX | = 1-10v + dmx | ||||||
| 450 | MG | = virtual midnight |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8056S14275GL | 275 | 4000°K - CRI>70 | on/off | 44877 | 163 | 615 | 240 | 120 | 9.5 | |||
| 8056S14300GL | 300 | 4000°K - CRI>70 | on/off | 48307 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14340GL | 340 | 4000°K - CRI>70 | on/off | 54205 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14380GL | 380 | 4000°K - CRI>70 | on/off | 60599 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14410GL | 410 | 4000°K - CRI>70 | on/off | 66041 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14450GL | 450 | 4000°K - CRI>70 | on/off | 70786 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056S14275GM | 275 | 4000°K - CRI>70 | 1-10v | 44877 | 163 | 615 | 240 | 120 | 9.5 | |||
| 8056S14300GM | 300 | 4000°K - CRI>70 | 1-10v | 48307 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14340GM | 340 | 4000°K - CRI>70 | 1-10v | 54205 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14380GM | 380 | 4000°K - CRI>70 | 1-10v | 60599 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14410GM | 410 | 4000°K - CRI>70 | 1-10v | 66041 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14450GM | 450 | 4000°K - CRI>70 | 1-10v | 70786 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056S14275GD | 275 | 4000°K - CRI>70 | dali | 44877 | 163 | 615 | 240 | 120 | 9.5 | |||
| 8056S14300GD | 300 | 4000°K - CRI>70 | dali | 48307 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14340GD | 340 | 4000°K - CRI>70 | dali | 54205 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14380GD | 380 | 4000°K - CRI>70 | dali | 60599 | 159 | 615 | 240 | 120 | 9.5 | |||
| 8056S14410GD | 410 | 4000°K - CRI>70 | dali | 66041 | 161 | 615 | 240 | 120 | 9.5 | |||
| 8056S14450GD | 450 | 4000°K - CRI>70 | dali | 70786 | 157 | 615 | 240 | 120 | 9.5 | |||
| 8056S14275G4 | 275 | 4000°K - CRI>70 | input 400Vac | 44877 | 163 | 615 | 240 | 120 | 9.5 | |||
| 8056S14300G4 | 300 | 4000°K - CRI>70 | input 400Vac | 48307 | 161 | 615 | 240 | 120 | 9.5 |
