| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 8400 | SU | 4 | = 4000°K (CRI >80) | 040 | 118 | GL | = on/off | ||||
| 5 | = 5000°K (CRI >80) | 058 | 130 | GD | = dali 2 | ||||||
| 065 | 140 | G3 | = em. 3h | ||||||||
| 080 | 150 | D3 | = dali 2 + em. 3h | ||||||||
| 090 | 170 | ||||||||||
| 100 | 190 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 8400SU4040GL | 40 | - | 4000°K - CRI>80 | on/off | 5763 | 144 | 365 | - | 150 | - | 5.5 | |
| 8400SU4058GL | 58 | - | 4000°K - CRI>80 | on/off | 9427 | 163 | 365 | - | 150 | - | 5.5 | |
| 8400SU4065GL | 65 | - | 4000°K - CRI>80 | on/off | 10485 | 161 | 365 | - | 150 | - | 5.5 | |
| 8400SU4080GL | 80 | - | 4000°K - CRI>80 | on/off | 13055 | 163 | 365 | - | 150 | - | 5.5 | |
| 8400SU4090GL | 90 | - | 4000°K - CRI>80 | on/off | 14559 | 162 | 365 | - | 150 | - | 5.5 | |
| 8400SU4100GL | 100 | - | 4000°K - CRI>80 | on/off | 15530 | 155 | 365 | - | 150 | - | 5.5 | |
| 8400SU4118GL | 118 | - | 4000°K - CRI>80 | on/off | 19044 | 159 | 365 | - | 150 | - | 5.5 | |
| 8400SU4130GL | 130 | - | 4000°K - CRI>80 | on/off | 20176 | 155 | 365 | - | 150 | - | 5.5 | |
| 8400SU4140GL | 140 | - | 4000°K - CRI>80 | on/off | 21326 | 152 | 365 | - | 150 | - | 5.5 | |
| 8400SU4150GL | 150 | - | 4000°K - CRI>80 | on/off | 22043 | 147 | 365 | - | 150 | - | 5.5 | |
| 8400SU4170GL | 170 | - | 4000°K - CRI>80 | on/off | 24836 | 146 | 365 | - | 150 | - | 5.5 | |
| 8400SU4190GL | 190 | - | 4000°K - CRI>80 | on/off | 29592 | 156 | 365 | - | 150 | - | 5.5 | |
| 8400SU4040GD | 40 | - | 4000°K - CRI>80 | dali 2 | 5763 | 144 | 365 | - | 150 | - | 5.5 | |
| 8400SU4058GD | 58 | - | 4000°K - CRI>80 | dali 2 | 9427 | 163 | 365 | - | 150 | - | 5.5 | |
| 8400SU4065GD | 65 | - | 4000°K - CRI>80 | dali 2 | 10485 | 161 | 365 | - | 150 | - | 5.5 | |
| 8400SU4080GD | 80 | - | 4000°K - CRI>80 | dali 2 | 13055 | 163 | 365 | - | 150 | - | 5.5 | |
| 8400SU4090GD | 90 | - | 4000°K - CRI>80 | dali 2 | 14559 | 162 | 365 | - | 150 | - | 5.5 | |
| 8400SU4100GD | 100 | - | 4000°K - CRI>80 | dali 2 | 15530 | 155 | 365 | - | 150 | - | 5.5 | |
| 8400SU4118GD | 118 | - | 4000°K - CRI>80 | dali 2 | 19044 | 159 | 365 | - | 150 | - | 5.5 | |
| 8400SU4130GD | 130 | - | 4000°K - CRI>80 | dali 2 | 20176 | 155 | 365 | - | 150 | - | 5.5 |
