MIG 2 – Mod. CP

(Asymmetrical pedestrian and cycle street lighting, Class P (type II/III)

LED fixture for lighting of urban, suburban roads, pedestrian paths, suitable for installation on pole head, horizontal arm, half pole (single or double) or wall. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder coating graphite color, die-cast aluminum heat sink with fin structure and extra-clear tempered flat glass diffuser 4 mm thick. Die-cast aluminum pole attachment, compatible with poles of ø 60-75 mm, with 0°/+90° adjustment on pole head and -20°/+ 20° on horizontal reach. Cyclopedestrian optic EN13201 Class P (Type II/III).

Categories: Led, MIG, MIG 2 - 9201, Street lighting, MIG 2

Models: 384

Color: Graphite

Catalogue abstract

Installation instructions

Photometric data

Legenda

Art.	Mod.	°K (CRI)		W tot.		Options
9201	CP	2	= ambra (CRI >70)	037	110	RL	= on/off
		3	= 3000°K (CRI >70)	050	120	RM	= 1-10v
		4	= 4000°K (CRI >70)	054	123	RD	= dali 2
		5	= 5000°K (CRI >70)	062	130	MR	= virtual midnight
				073	150	RZ	= zhaga socket dali D4i
				078	160	ZR	= zhaga socket dali D4i up&down
				091	170
				104	200

Models

Codice	W tot.	mA	°K - CRI	Options	Lumen OUTPUT	Lm/W	L (mm)	P (mm)	H (mm)	D (mm)	Kg
9201CP4037RL	37	-	4000°K - CRI>70	on/off	6655	180	325	490	65	-	6.7
9201CP4050RL	50	-	4000°K - CRI>70	on/off	8873	177	325	490	65	-	6.7
9201CP4062RL	62	-	4000°K - CRI>70	on/off	11091	179	325	490	65	-	6.7
9201CP4054RL	54	-	4000°K - CRI>70	on/off	9333	173	325	490	65	-	6.7
9201CP4073RL	73	-	4000°K - CRI>70	on/off	12444	170	325	490	65	-	6.7
9201CP4091RL	91	-	4000°K - CRI>70	on/off	15554	171	325	490	65	-	6.7
9201CP4078RL	78	-	4000°K - CRI>70	on/off	12735	163	325	490	65	-	6.7
9201CP4104RL	104	-	4000°K - CRI>70	on/off	16980	163	325	490	65	-	6.7
9201CP4130RL	130	-	4000°K - CRI>70	on/off	21225	163	325	490	65	-	6.7
9201CP4110RL	110	-	4000°K - CRI>70	on/off	18073	164	325	490	65	-	6.7
9201CP4123RL	123	-	4000°K - CRI>70	on/off	19680	160	325	490	65	-	6.7
9201CP4120RL	120	-	4000°K - CRI>70	on/off	18202	152	325	490	65	-	6.7
9201CP4150RL	150	-	4000°K - CRI>70	on/off	23080	154	325	490	65	-	6.7
9201CP4160RL	160	-	4000°K - CRI>70	on/off	24269	152	325	490	65	-	6.7
9201CP4170RL	170	-	4000°K - CRI>70	on/off	26561	156	325	490	65	-	6.7
9201CP4200RL	200	-	4000°K - CRI>70	on/off	30337	152	325	490	65	-	6.7
9201CP4037RM	37	-	4000°K - CRI>70	1-10v	6655	180	325	490	65	-	6.7
9201CP4050RM	50	-	4000°K - CRI>70	1-10v	8873	177	325	490	65	-	6.7
9201CP4062RM	62	-	4000°K - CRI>70	1-10v	11091	179	325	490	65	-	6.7
9201CP4054RM	54	-	4000°K - CRI>70	1-10v	9333	173	325	490	65	-	6.7
