art.-7030-polar-hp-rr-silver

POLAR HP – Mod. RR

(65° asymmetric optics)

Led floodlight for indoor and outdoor use. Suitable for ground, wall, pole or ceiling installation. Die-cast aluminum body painted with anti-corrosion polyester thermosetting powder in anthracite. Extra-clear tempered flat glass diffuser 4 mm thick, silicone gasket. Available with asymmetrical 65° optics.
Categories: Led, POLAR, POLAR HP - 7030, Floodlights, POLAR HP
Models: 468
Color: Silver
Catalogue abstract
Installation instructions
Photometric data

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7030RR2= ambra (CRI >80) 040GL= on/off
3= 3000°K (CRI >80)050GD= dali 2
4= 4000°K (CRI >80)060GA= acid-etched glass
5= 5000°K (CRI >80)070G2= class II
080
090
100
120
130
150
160
175
190

Models

W tot.
°K - CRI
Options
DownloadCodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WL (mm)P (mm)H (mm)D (mm)Kg
7030RR4040GL40-4000°K - CRI>80on/off681717029555425-5.6
7030RR4050GL50-4000°K - CRI>80on/off847116929555425-5.6
7030RR4060GL60-4000°K - CRI>80on/off1009516829555425-5.6
7030RR4070GL70-4000°K - CRI>80on/off1167416729555425-5.6
7030RR4080GL80-4000°K - CRI>80on/off1372717229555425-5.6
7030RR4090GL90-4000°K - CRI>80on/off1512316829555425-5.6
7030RR4100GL100-4000°K - CRI>80on/off1681016829555425-5.6
7030RR4120GL120-4000°K - CRI>80on/off1927816129555425-5.6
7030RR4130GL130-4000°K - CRI>80on/off2077116029555425-5.6
7030RR4150GL150-4000°K - CRI>80on/off2297415329555425-5.6
7030RR4160GL160-4000°K - CRI>80on/off2514215729555425-5.6
7030RR4175GL175-4000°K - CRI>80on/off2656215229555425-5.6
7030RR4190GL190-4000°K - CRI>80on/off2979615729555425-5.6
7030RR4040GD40-4000°K - CRI>80dali681717029555425-5.6
7030RR4050GD50-4000°K - CRI>80dali847116929555425-5.6
7030RR4060GD60-4000°K - CRI>80dali1009516829555425-5.6
7030RR4070GD70-4000°K - CRI>80dali1167416729555425-5.6
7030RR4080GD80-4000°K - CRI>80dali1372717229555425-5.6
7030RR4090GD90-4000°K - CRI>80dali1512316829555425-5.6
7030RR4100GD100-4000°K - CRI>80dali1681016829555425-5.6

Accessories
