art.-7051-snap-c3-c6-p3-p6-corten

SNAP/P3

Indoor and outdoor led floodlight. Die-cast aluminum body painted with corten epoxy powders. AC direct 220-240V 50/60Hz led boards. Manufactured in accordance with EN / IEC 60598-1.
Categories: Led, SNAP - 7051, Architectural Outdoor, art. 7051 Snap, SNAP
Models: 18
Color: Corten
Catalogue abstract
Installation instructions

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7051P327= 2700°K (CRI >80)05CL= on/off
30= 3000°K (CRI >80)10
40= 4000°K (CRI >80)15

Models

W tot.
°K - CRI
Options
CodiceW tot.mA°K - CRIOptionsLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7051P34005CL5-4000°K - CRI>80on/off5011007045164-0.60
7051P34010CL10-4000°K - CRI>80on/off10021007045164-0.60
7051P34015CL15-4000°K - CRI>80on/off15021007045164-0.60
7051P33005CL5-3000°K - CRI>80on/off468947045164-0.60
7051P33010CL10-3000°K - CRI>80on/off937947045164-0.60
7051P33015CL15-3000°K - CRI>80on/off1404947045164-0.60
7051P32705CL5-2700°K - CRI>80on/off453917045164-0.60
7051P32710CL10-2700°K - CRI>80on/off907917045164-0.60
7051P32715CL15-2700°K - CRI>80on/off1359917045164-0.60
7051P34005CL5-4000°K - CRI>80on/off5011007045164-0.60
7051P34010CL10-4000°K - CRI>80on/off10021007045164-0.60
7051P34015CL15-4000°K - CRI>80on/off15021007045164-0.60
7051P33005CL5-3000°K - CRI>80on/off468947045164-0.60
7051P33010CL10-3000°K - CRI>80on/off937947045164-0.60
7051P33015CL15-3000°K - CRI>80on/off1404947045164-0.60
7051P32705CL5-2700°K - CRI>80on/off453917045164-0.60
7051P32710CL10-2700°K - CRI>80on/off907917045164-0.60
7051P32715CL15-2700°K - CRI>80on/off1359917045164-0.60

Accessories
