| Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 7055 | S6 | 27 | = 2700°K (CRI >80) | 10 | GL | = on/off | ||||
| 30 | = 3000°K (CRI >80) | 20 | GD | = dali 2 | ||||||
| 40 | = 4000°K (CRI >80) | 30 |
| Codice | W tot. | mA | °K - CRI | Options | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7055S64010GL | 10 | - | 4000°K - CRI>80 | on/off | 1305 | 130 | 105 | - | 220 | - | 1.3 | |
| 7055S64020GL | 20 | - | 4000°K - CRI>80 | on/off | 2335 | 117 | 105 | - | 220 | - | 1.3 | |
| 7055S64030GL | 30 | - | 4000°K - CRI>80 | on/off | 3308 | 110 | 105 | - | 220 | - | 1.3 | |
| 7055S64010GD | 10 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 1305 | 130 | 105 | - | 220 | - | 1.3 | |
| 7055S64020GD | 20 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 2335 | 117 | 105 | - | 220 | - | 1.3 | |
| 7055S64030GD | 30 | - | 4000°K - CRI>80 | dali 2 / dali 2 push | 3308 | 110 | 105 | - | 220 | - | 1.3 | |
| 7055S63010GL | 10 | - | 3000°K - CRI>80 | on/off | 1243 | 124 | 105 | - | 220 | - | 1.3 | |
| 7055S63020GL | 20 | - | 3000°K - CRI>80 | on/off | 2223 | 111 | 105 | - | 220 | - | 1.3 | |
| 7055S63030GL | 30 | - | 3000°K - CRI>80 | on/off | 3150 | 105 | 105 | - | 220 | - | 1.3 | |
| 7055S63010GD | 10 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 1243 | 124 | 105 | - | 220 | - | 1.3 | |
| 7055S63020GD | 20 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 2223 | 111 | 105 | - | 220 | - | 1.3 | |
| 7055S63030GD | 30 | - | 3000°K - CRI>80 | dali 2 / dali 2 push | 3150 | 105 | 105 | - | 220 | - | 1.3 | |
| 7055S62710GL | 10 | - | 2700°K - CRI>80 | on/off | 1182 | 118 | 105 | - | 220 | - | 1.3 | |
| 7055S62720GL | 20 | - | 2700°K - CRI>80 | on/off | 2116 | 106 | 105 | - | 220 | - | 1.3 | |
| 7055S62730GL | 30 | - | 2700°K - CRI>80 | on/off | 2997 | 100 | 105 | - | 220 | - | 1.3 | |
| 7055S62710GD | 10 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 1182 | 118 | 105 | - | 220 | - | 1.3 | |
| 7055S62720GD | 20 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 2116 | 106 | 105 | - | 220 | - | 1.3 | |
| 7055S62730GD | 30 | - | 2700°K - CRI>80 | dali 2 / dali 2 push | 2997 | 100 | 105 | - | 220 | - | 1.3 |
