COSMIC 3/C3

Indoor and outdoor led floodlight, suitable for large areas and sports areas. Silver Extruded oxidate aluminium body, zinc-coated and painted bracket, 4 mm thick tempered transparent glass, silicon gasket, electronic driver 220-240V 50/60Hz. Manufactured in accordance with EN / IEC 60598-1.

Categories: Led, COSMIC 3 - 8059, Floodlights, art. 8059 Cosmic 3

Models: 150

Color: Silver

Catalogue abstract

Installation instructions

Legenda

Art.	Mod.	°K (CRI)		W tot.		Options
8059	C3	3	= 3000°K (CRI >70)	815		GL	= on/off
		4	= 4000°K (CRI >70)	885		GM	= 1-10v
		5	= 5000°K (CRI >70)	100	=1000W	GD	= dali
		7	= 5700°K (CRI >70)	120	=1200W	G4	= input 400Vac
		R	= 5700°K (CRI >90)	135	=1350W	GX	= 1-10v + dmx
						MG	= virtual midnight

Models

Codice	W tot.	mA	°K - CRI	Options	Lumen OUTPUT	Lm/W	A (mm)	B (mm)	C (mm)	D (mm)	Kg
8059C34815GL	815	-	4000°K - CRI>70	on/off	143116	166	680	710	255	610	28.5
8059C34885GL	885	-	4000°K - CRI>70	on/off	154159	165	680	710	255	610	28.5
8059C34100GL	1000	-	4000°K - CRI>70	on/off	168511	160	680	710	255	610	28.5
8059C34120GL	1200	-	4000°K - CRI>70	on/off	189778	150	680	710	255	610	28.5
8059C34135GL	1350	-	4000°K - CRI>70	on/off	214890	151	680	710	255	610	28.5
8059C34815GM	815	-	4000°K - CRI>70	1-10v	143116	166	680	710	255	610	28.5
8059C34885GM	885	-	4000°K - CRI>70	1-10v	154159	165	680	710	255	610	28.5
8059C34100GM	1000	-	4000°K - CRI>70	1-10v	168511	160	680	710	255	610	28.5
8059C34120GM	1200	-	4000°K - CRI>70	1-10v	189778	150	680	710	255	610	28.5
8059C34135GM	1350	-	4000°K - CRI>70	1-10v	214890	151	680	710	255	610	28.5
8059C34815GD	815	-	4000°K - CRI>70	dali	143116	166	680	710	255	610	28.5
8059C34885GD	885	-	4000°K - CRI>70	dali	154159	165	680	710	255	610	28.5
8059C34100GD	1000	-	4000°K - CRI>70	dali	168511	160	680	710	255	610	28.5
8059C34120GD	1200	-	4000°K - CRI>70	dali	189778	150	680	710	255	610	28.5
8059C34135GD	1350	-	4000°K - CRI>70	dali	214890	151	680	710	255	610	28.5
8059C34815G4	815	-	4000°K - CRI>70	input 400Vac	143116	166	680	710	255	610	28.5
8059C34885G4	885	-	4000°K - CRI>70	input 400Vac	154159	165	680	710	255	610	28.5
8059C34100G4	1000	-	4000°K - CRI>70	input 400Vac	168511	160	680	710	255	610	28.5
8059C34120G4	1200	-	4000°K - CRI>70	input 400Vac	189778	150	680	710	255	610	28.5
8059C34135G4	1350	-	4000°K - CRI>70	input 400Vac	214890	151	680	710	255	610	28.5
