Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
---|---|---|---|---|---|---|---|---|---|---|---|
3001 | W1 | 27 | = 2700°K (CRI >80) | 08 | 36 | GL | = on/off | ||||
30 | = 3000°K (CRI >80) | 12 | 42 | GD | = dali 2 | ||||||
40 | = 4000°K (CRI >80) | 16 | 49 | FC | = fila continua | ||||||
93 | = 3000°K (CRI >90) | 17 | 52 | FD | = fila continua + dali 2 | ||||||
94 | = 4000°K (CRI >90) | 24 | 61 | ||||||||
26 | 70 | ||||||||||
32 | 88 | ||||||||||
35 |
Codice | W tot. | mA | °K - CRI | Opzioni | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
3001W14008GL | 8 | - | 4000°K - CRI>80 | on/off | 1082 | 135 | 110 | 70 | 400 | - | 2.2 | |
3001W14012GL | 12 | - | 4000°K - CRI>80 | on/off | 1488 | 124 | 110 | 70 | 400 | - | 2.2 | |
3001W14017GL | 17 | - | 4000°K - CRI>80 | on/off | 1985 | 117 | 110 | 70 | 400 | - | 2.2 | |
3001W14016GL | 16 | - | 4000°K - CRI>80 | on/off | 2165 | 135 | 110 | 70 | 680 | - | 3.2 | |
3001W14024GL | 24 | - | 4000°K - CRI>80 | on/off | 2978 | 124 | 110 | 70 | 680 | - | 3.2 | |
3001W14035GL | 35 | - | 4000°K - CRI>80 | on/off | 3970 | 113 | 110 | 70 | 680 | - | 3.2 | |
3001W14026GL | 26 | - | 4000°K - CRI>80 | on/off | 3456 | 133 | 110 | 70 | 960 | - | 4.2 | |
3001W14036GL | 36 | - | 4000°K - CRI>80 | on/off | 4466 | 124 | 110 | 70 | 960 | - | 4.2 | |
3001W14052GL | 52 | - | 4000°K - CRI>80 | on/off | 5955 | 115 | 110 | 70 | 960 | - | 4.2 | |
3001W14032GL | 32 | - | 4000°K - CRI>80 | on/off | 4330 | 135 | 110 | 70 | 1240 | - | 5.2 | |
3001W14049GL | 49 | - | 4000°K - CRI>80 | on/off | 5955 | 122 | 110 | 70 | 1240 | - | 5.2 | |
3001W14070GL | 70 | - | 4000°K - CRI>80 | on/off | 7941 | 113 | 110 | 70 | 1240 | - | 5.2 | |
3001W14042GL | 42 | - | 4000°K - CRI>80 | on/off | 5412 | 129 | 110 | 70 | 1520 | - | 5.9 | |
3001W14061GL | 61 | - | 4000°K - CRI>80 | on/off | 7443 | 122 | 110 | 70 | 1520 | - | 5.9 | |
3001W14088GL | 88 | - | 4000°K - CRI>80 | on/off | 9925 | 113 | 110 | 70 | 1520 | - | 5.9 | |
3001W14008GD | 8 | - | 4000°K - CRI>80 | dali | 1082 | 135 | 110 | 70 | 400 | - | 2.2 | |
3001W14012GD | 12 | - | 4000°K - CRI>80 | dali | 1488 | 124 | 110 | 70 | 400 | - | 2.2 | |
3001W14017GD | 17 | - | 4000°K - CRI>80 | dali | 1985 | 117 | 110 | 70 | 400 | - | 2.2 | |
3001W14016GD | 16 | - | 4000°K - CRI>80 | dali | 2165 | 135 | 110 | 70 | 680 | - | 3.2 | |
3001W14024GD | 24 | - | 4000°K - CRI>80 | dali | 2978 | 124 | 110 | 70 | 680 | - | 3.2 |
