Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
---|---|---|---|---|---|---|---|---|---|---|
7023 | AB | 27 | = 2700°K (CRI >80) | 03 | GS | = 250 mm | ||||
30 | = 3000°K (CRI >80) | 06 | GM | = 500 mm | ||||||
40 | = 4000°K (CRI >80) | 09 | GL | = 1000 mm | ||||||
GB | = 1500 mm |
Codice | W tot. | mA | °K - CRI | Opzioni | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
7023AB4003GS | 3 | - | 4000°K - CRI>80 | 250 mm | 307 | 102 | 60 | 60 | 250 | - | 0.80 | |
7023AB4006GS | 6 | - | 4000°K - CRI>80 | 250 mm | 613 | 102 | 60 | 60 | 250 | - | 0.80 | |
7023AB4009GS | 9 | - | 4000°K - CRI>80 | 250 mm | 818 | 91 | 60 | 60 | 250 | - | 0.80 | |
7023AB4003GM | 3 | - | 4000°K - CRI>80 | 500 mm | 307 | 102 | 60 | 60 | 250 | - | 1.2 | |
7023AB4006GM | 6 | - | 4000°K - CRI>80 | 500 mm | 613 | 102 | 60 | 60 | 500 | - | 1.2 | |
7023AB4009GM | 9 | - | 4000°K - CRI>80 | 500 mm | 818 | 91 | 60 | 60 | 500 | - | 1.2 | |
7023AB4014GM | 14 | - | 4000°K - CRI>80 | 500 mm | 1130 | 81 | 60 | 60 | 500 | - | 1.2 | |
7023AB4003GL | 3 | - | 4000°K - CRI>80 | 1000 mm | 307 | 102 | 60 | 60 | 1000 | - | 2.2 | |
7023AB4006GL | 6 | - | 4000°K - CRI>80 | 1000 mm | 613 | 102 | 60 | 60 | 1000 | - | 2.2 | |
7023AB4009GL | 9 | - | 4000°K - CRI>80 | 1000 mm | 818 | 91 | 60 | 60 | 1000 | - | 2.2 | |
7023AB4014GL | 14 | - | 4000°K - CRI>80 | 1000 mm | 1130 | 81 | 60 | 60 | 1000 | - | 2.2 | |
7023AB4003GB | 3 | - | 4000°K - CRI>80 | 1500 mm | 307 | 102 | 60 | 60 | 1500 | - | 3.2 | |
7023AB4006GB | 6 | - | 4000°K - CRI>80 | 1500 mm | 613 | 102 | 60 | 60 | 1500 | - | 3.2 | |
7023AB4009GB | 9 | - | 4000°K - CRI>80 | 1500 mm | 818 | 91 | 60 | 60 | 1500 | - | 3.2 | |
7023AB4014GB | 14 | - | 4000°K - CRI>80 | 1500 mm | 1130 | 81 | 60 | 60 | 1500 | - | 3.2 | |
7023AB3003GS | 3 | - | 3000°K - CRI>80 | 250 mm | 287 | 96 | 60 | 60 | 250 | - | 0.80 | |
7023AB3006GS | 6 | - | 3000°K - CRI>80 | 250 mm | 573 | 96 | 60 | 60 | 250 | - | 0.80 | |
7023AB3009GS | 9 | - | 3000°K - CRI>80 | 250 mm | 765 | 85 | 60 | 60 | 250 | - | 0.80 | |
7023AB3003GM | 3 | - | 3000°K - CRI>80 | 500 mm | 287 | 96 | 60 | 60 | 250 | - | 1.2 | |
7023AB3006GM | 6 | - | 3000°K - CRI>80 | 500 mm | 573 | 96 | 60 | 60 | 500 | - | 1.2 |
