Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
---|---|---|---|---|---|---|---|---|---|---|
7024 | AB | 27 | = 2700°K (CRI >80) | 10 | G1 | = 500 mm | ||||
30 | = 3000°K (CRI >80) | 20 | G2 | = 1000 mm | ||||||
40 | = 4000°K (CRI >80) | 30 | G3 | = 1500 mm |
Codice | W tot. | mA | °K - CRI | Opzioni | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
7024AB4010G1 | 10 | - | 4000°K - CRI>80 | 500 mm | 1163 | 116 | 95 | 305 | 500 | - | 2.2 | |
7024AB4020G1 | 20 | - | 4000°K - CRI>80 | 500 mm | 2325 | 116 | 95 | 305 | 500 | - | 2.2 | |
7024AB4030G1 | 30 | - | 4000°K - CRI>80 | 500 mm | 3487 | 116 | 95 | 305 | 500 | - | 2.2 | |
7024AB4010G2 | 10 | - | 4000°K - CRI>80 | 1000 mm | 1163 | 116 | 95 | 305 | 1000 | - | 3.1 | |
7024AB4020G2 | 20 | - | 4000°K - CRI>80 | 1000 mm | 2325 | 116 | 95 | 305 | 1000 | - | 3.1 | |
7024AB4030G2 | 30 | - | 4000°K - CRI>80 | 1000 mm | 3487 | 116 | 95 | 305 | 1000 | - | 3.1 | |
7024AB4010G3 | 10 | - | 4000°K - CRI>80 | 1500 mm | 1163 | 116 | 95 | 305 | 1500 | - | 4.5 | |
7024AB4020G3 | 20 | - | 4000°K - CRI>80 | 1500 mm | 2325 | 116 | 95 | 305 | 1500 | - | 4.5 | |
7024AB4030G3 | 30 | - | 4000°K - CRI>80 | 1500 mm | 3487 | 116 | 95 | 305 | 1500 | - | 4.5 | |
7024AB3010G1 | 10 | - | 3000°K - CRI>80 | 500 mm | 1154 | 115 | 95 | 305 | 500 | - | 2.2 | |
7024AB3020G1 | 20 | - | 3000°K - CRI>80 | 500 mm | 2306 | 115 | 95 | 305 | 500 | - | 2.2 | |
7024AB3030G1 | 30 | - | 3000°K - CRI>80 | 500 mm | 3459 | 115 | 95 | 305 | 500 | - | 2.2 | |
7024AB3010G2 | 10 | - | 3000°K - CRI>80 | 1000 mm | 1154 | 115 | 95 | 305 | 1000 | - | 3.1 | |
7024AB3020G2 | 20 | - | 3000°K - CRI>80 | 1000 mm | 2306 | 115 | 95 | 305 | 1000 | - | 3.1 | |
7024AB3030G2 | 30 | - | 3000°K - CRI>80 | 1000 mm | 3459 | 115 | 95 | 305 | 1000 | - | 3.1 | |
7024AB3010G3 | 10 | - | 3000°K - CRI>80 | 1500 mm | 1154 | 115 | 95 | 305 | 1500 | - | 4.5 | |
7024AB3020G3 | 20 | - | 3000°K - CRI>80 | 1500 mm | 2306 | 115 | 95 | 305 | 1500 | - | 4.5 | |
7024AB3030G3 | 30 | - | 3000°K - CRI>80 | 1500 mm | 3459 | 115 | 95 | 305 | 1500 | - | 4.5 | |
7024AB2710G1 | 10 | - | 2700°K - CRI>80 | 500 mm | 1101 | 110 | 95 | 305 | 500 | - | 2.2 | |
7024AB2720G1 | 20 | - | 2700°K - CRI>80 | 500 mm | 2202 | 110 | 95 | 305 | 500 | - | 2.2 |
