Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | ||
---|---|---|---|---|---|---|---|---|---|---|
7024 | AM | 27 | = 2700°K (CRI >80) | 5 | C1 | = 500 mm | ||||
30 | = 3000°K (CRI >80) | 10 | C2 | = 1000 mm | ||||||
40 | = 4000°K (CRI >80) | 15 | C3 | = 1500 mm |
Codice | W tot. | mA | °K - CRI | Opzioni | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
7024AM4005C1 | 5 | - | 4000°K - CRI>80 | 500 mm | 581 | 116 | 95 | 165 | 500 | - | 1.8 | |
7024AM4010C1 | 10 | - | 4000°K - CRI>80 | 500 mm | 1163 | 116 | 95 | 165 | 500 | - | 1.8 | |
7024AM4015C1 | 15 | - | 4000°K - CRI>80 | 500 mm | 1744 | 116 | 95 | 165 | 500 | - | 1.8 | |
7024AM4005C2 | 5 | - | 4000°K - CRI>80 | 1000 mm | 581 | 116 | 95 | 165 | 1000 | - | 2.5 | |
7024AM4010C2 | 10 | - | 4000°K - CRI>80 | 1000 mm | 1163 | 116 | 95 | 165 | 1000 | - | 2.5 | |
7024AM4015C2 | 15 | - | 4000°K - CRI>80 | 1000 mm | 1744 | 116 | 95 | 165 | 1000 | - | 2.5 | |
7024AM4005C3 | 5 | - | 4000°K - CRI>80 | 1500 mm | 581 | 116 | 95 | 165 | 1500 | - | 3.7 | |
7024AM4010C3 | 10 | - | 4000°K - CRI>80 | 1500 mm | 1163 | 116 | 95 | 165 | 1500 | - | 3.7 | |
7024AM4015C3 | 15 | - | 4000°K - CRI>80 | 1500 mm | 1744 | 116 | 95 | 165 | 1500 | - | 3.7 | |
7024AM3005C1 | 5 | - | 3000°K - CRI>80 | 500 mm | 576 | 115 | 95 | 165 | 500 | - | 1.8 | |
7024AM3010C1 | 10 | - | 3000°K - CRI>80 | 500 mm | 1154 | 115 | 95 | 165 | 500 | - | 1.8 | |
7024AM3015C1 | 15 | - | 3000°K - CRI>80 | 500 mm | 1730 | 115 | 95 | 165 | 500 | - | 1.8 | |
7024AM3005C2 | 5 | - | 3000°K - CRI>80 | 1000 mm | 576 | 115 | 95 | 165 | 1000 | - | 2.5 | |
7024AM3010C2 | 10 | - | 3000°K - CRI>80 | 1000 mm | 1154 | 115 | 95 | 165 | 1000 | - | 2.5 | |
7024AM3015C2 | 15 | - | 3000°K - CRI>80 | 1000 mm | 1730 | 115 | 95 | 165 | 1000 | - | 2.5 | |
7024AM3005C3 | 5 | - | 3000°K - CRI>80 | 1500 mm | 576 | 115 | 95 | 165 | 1500 | - | 3.7 | |
7024AM3010C3 | 10 | - | 3000°K - CRI>80 | 1500 mm | 1154 | 115 | 95 | 165 | 1500 | - | 3.7 | |
7024AM3015C3 | 15 | - | 3000°K - CRI>80 | 1500 mm | 1730 | 115 | 95 | 165 | 1500 | - | 3.7 | |
7024AM2705C1 | 5 | - | 2700°K - CRI>80 | 500 mm | 550 | 110 | 95 | 165 | 500 | - | 1.8 | |
7024AM2710C1 | 10 | - | 2700°K - CRI>80 | 500 mm | 1101 | 110 | 95 | 165 | 500 | - | 1.8 |
