art-7104-magic-4-mr-cr-sr-tr-ar-rr

MAGIC 4/AR

Proiettore led per interni ed esterni adatto per l’illuminazione di grandi aree ed impianti sportivi. Corpo in alluminio pressofuso verniciato con polvere termoindurente poliestere anticorrosione colore silver, driver elettronico 220-240V 50/60Hz. Prodotto in conformità alle vigenti norme EN / IEC 60598-1.
Categorie: Led, Proiettori, Magic 4
Codici: 72
Colore: Silver

Legenda

Art.+Mod.+°K (CRI)+W tot.+Options
7104AR4= 4000°K (CRI >70)120=1200WGL= on/off
7= 5700°K (CRI >70)150=1500WGM= 1-10v
R= 5700°K (CRI >90)160=1600WGD= dali
180=1800WG4= input 400Vac
GX= 1-10v + dmx
MG= mezzanotte virtuale

Codici

W tot.
°K - CRI
Opzioni
CodiceW tot.mA°K - CRIOpzioniLumen OUTPUTLm/WA (mm)B (mm)C (mm)D (mm)Kg
7104ARR180MG1800-5700°K - CRI>90mezzanotte virtuale192961107655350980-45.5
7104ARR160MG1600-5700°K - CRI>90mezzanotte virtuale173649109655350980-45.5
7104ARR150MG1500-5700°K - CRI>90mezzanotte virtuale166967111655350980-45.5
7104ARR120MG1200-5700°K - CRI>90mezzanotte virtuale139010116655350980-45.5
7104ARR180GX1800-5700°K - CRI>901-10v + dmx192961107655350980-45.5
7104ARR160GX1600-5700°K - CRI>901-10v + dmx173649109655350980-45.5
7104ARR150GX1500-5700°K - CRI>901-10v + dmx166967111655350980-45.5
7104ARR120GX1200-5700°K - CRI>901-10v + dmx139010116655350980-45.5
7104ARR180G41800-5700°K - CRI>90input 400Vac192961107655350980-45.5
7104ARR160G41600-5700°K - CRI>90input 400Vac173649109655350980-45.5
7104ARR150G41500-5700°K - CRI>90input 400Vac166967111655350980-45.5
7104ARR120G41200-5700°K - CRI>90input 400Vac139010116655350980-45.5
7104ARR180GD1800-5700°K - CRI>90dali192961107655350980-45.5
7104ARR160GD1600-5700°K - CRI>90dali173649109655350980-45.5
7104ARR150GD1500-5700°K - CRI>90dali166967111655350980-45.5
7104ARR120GD1200-5700°K - CRI>90dali139010116655350980-45.5
7104ARR180GM1800-5700°K - CRI>901-10v192961107655350980-45.5
7104ARR160GM1600-5700°K - CRI>901-10v173649109655350980-45.5
7104ARR150GM1500-5700°K - CRI>901-10v166967111655350980-45.5
7104ARR120GM1200-5700°K - CRI>901-10v139010116655350980-45.5

Accessori
