FOX 2/C1

Proiettore architetturale per interni ed esterni. Corpo in alluminio pressofuso verniciato con polvere termoindurente poliestere anticorrosione colore antracite, vetro temperato trasparente spessore 4 mm, guarnizione in silicone, driver elettronico 220-240V 50/60Hz. Prodotto in conformità alle vigenti norme EN / IEC 60598-1.

Categorie: Led, Architectural Outdoor, Fox 2

Codici: 38

Colore: Antracite

Legenda

Art.	Mod.	°K (CRI)		W tot.	Options
7127	C1	27	= 2700°K (CRI >80)	50	EL	= on/off	(only white led version)
		30	= 3000°K (CRI >80)	60	LD	= dali	(only white led version)
		40	= 4000°K (CRI >80)	80	CS	= casambi bluetooth	(only RBG+W version)
		97	= 2700°K (CRI >90)		CG	= external gateway	(only RBG+W version)
		93	= 3000°K (CRI >90)
		94	= 4000°K (CRI >90)
		RW	= RGB+W

Codici

Codice	W tot.	mA	°K - CRI	Opzioni	Lumen OUTPUT	Lm/W	A (mm)	B (mm)	C (mm)	D (mm)	Kg
7127C1RW60CG	60	-	RGB+W - CRI>80	external gateway	2518	42	205	50	365	-	3.7
7127C1RW60CS	60	-	RGB+W - CRI>80	casambi bluetooth	2518	42	205	50	365	-	3.7
7127C19480LD	80	-	4000°K - CRI>90	dali	7761	97	205	50	365	-	3.7
7127C19460LD	60	-	4000°K - CRI>90	dali	6219	104	205	50	365	-	3.7
7127C19450LD	50	-	4000°K - CRI>90	dali	5262	105	205	50	365	-	3.7
7127C19480EL	80	-	4000°K - CRI>90	on/off	7761	97	205	50	365	-	3.7
7127C19460EL	60	-	4000°K - CRI>90	on/off	6219	104	205	50	365	-	3.7
7127C19450EL	50	-	4000°K - CRI>90	on/off	5262	105	205	50	365	-	3.7
7127C19780LD	80	-	2700°K - CRI>90	dali	7023	88	205	50	365	-	3.7
7127C19760LD	60	-	2700°K - CRI>90	dali	5628	94	205	50	365	-	3.7
7127C19750LD	50	-	2700°K - CRI>90	dali	4762	95	205	50	365	-	3.7
7127C19780EL	80	-	2700°K - CRI>90	on/off	7023	88	205	50	365	-	3.7
7127C19760EL	60	-	2700°K - CRI>90	on/off	5628	94	205	50	365	-	3.7
7127C19750EL	50	-	2700°K - CRI>90	on/off	4762	95	205	50	365	-	3.7
7127C19380LD	80	-	3000°K - CRI>90	dali	7403	93	205	50	365	-	3.7
7127C19360LD	60	-	3000°K - CRI>90	dali	5933	99	205	50	365	-	3.7
7127C19350LD	50	-	3000°K - CRI>90	dali	5019	100	205	50	365	-	3.7
7127C19380EL	80	-	3000°K - CRI>90	on/off	7403	93	205	50	365	-	3.7
7127C19360EL	60	-	3000°K - CRI>90	on/off	5933	99	205	50	365	-	3.7
7127C19350EL	50	-	3000°K - CRI>90	on/off	5019	100	205	50	365	-	3.7
