Art. | + | Mod. | + | °K (CRI) | + | W tot. | + | Options | |||
---|---|---|---|---|---|---|---|---|---|---|---|
7128 | C3 | 2 | = 2700°K (CRI >80) | 120 | EL | = on/off | (only white led version) | ||||
3 | = 3000°K (CRI >80) | 150 | LD | = dali | (only white led version) | ||||||
4 | = 4000°K (CRI >80) | CS | = casambi bluetooth | (only RBG+W version) | |||||||
7 | = 2700°K (CRI >90) | CG | = external gateway | (only RBG+W version) | |||||||
8 | = 3000°K (CRI >90) | ||||||||||
9 | = 4000°K (CRI >90) | ||||||||||
R | = RGB+W |
Codice | W tot. | mA | °K - CRI | Opzioni | Lumen OUTPUT | Lm/W | A (mm) | B (mm) | C (mm) | D (mm) | Kg | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
7128C34120EL | 120 | - | 4000°K - CRI>80 | on/off | 13318 | 111 | 295 | 55 | 425 | - | 5.6 | |
7128C34150EL | 150 | - | 4000°K - CRI>80 | on/off | 16024 | 107 | 295 | 55 | 425 | - | 5.6 | |
7128C34120LD | 120 | - | 4000°K - CRI>80 | dali | 13318 | 111 | 295 | 55 | 425 | - | 5.6 | |
7128C34150LD | 150 | - | 4000°K - CRI>80 | dali | 16024 | 107 | 295 | 55 | 425 | - | 5.6 | |
7128C33120EL | 120 | - | 3000°K - CRI>80 | on/off | 12615 | 105 | 295 | 55 | 425 | - | 5.6 | |
7128C33150EL | 150 | - | 3000°K - CRI>80 | on/off | 15178 | 101 | 295 | 55 | 425 | - | 5.6 | |
7128C33120LD | 120 | - | 3000°K - CRI>80 | dali | 12615 | 105 | 295 | 55 | 425 | - | 5.6 | |
7128C33150LD | 150 | - | 3000°K - CRI>80 | dali | 15178 | 101 | 295 | 55 | 425 | - | 5.6 | |
7128C32120EL | 120 | - | 2700°K - CRI>80 | on/off | 12071 | 101 | 295 | 55 | 425 | - | 5.6 | |
7128C32150EL | 150 | - | 2700°K - CRI>80 | on/off | 14524 | 97 | 295 | 55 | 425 | - | 5.6 | |
7128C32120LD | 120 | - | 2700°K - CRI>80 | dali | 12071 | 101 | 295 | 55 | 425 | - | 5.6 | |
7128C32150LD | 150 | - | 2700°K - CRI>80 | dali | 14524 | 97 | 295 | 55 | 425 | - | 5.6 | |
7128C38120EL | 120 | - | 3000°K - CRI>90 | on/off | 10887 | 91 | 295 | 55 | 425 | - | 5.6 | |
7128C38150EL | 150 | - | 3000°K - CRI>90 | on/off | 13100 | 87 | 295 | 55 | 425 | - | 5.6 | |
7128C38120LD | 120 | - | 3000°K - CRI>90 | dali | 10887 | 91 | 295 | 55 | 425 | - | 5.6 | |
7128C38150LD | 150 | - | 3000°K - CRI>90 | dali | 13100 | 87 | 295 | 55 | 425 | - | 5.6 | |
7128C37120EL | 120 | - | 2700°K - CRI>90 | on/off | 10328 | 86 | 295 | 55 | 425 | - | 5.6 | |
7128C37150EL | 150 | - | 2700°K - CRI>90 | on/off | 12427 | 83 | 295 | 55 | 425 | - | 5.6 | |
7128C37120LD | 120 | - | 2700°K - CRI>90 | dali | 10328 | 86 | 295 | 55 | 425 | - | 5.6 | |
7128C37150LD | 150 | - | 2700°K - CRI>90 | dali | 12427 | 83 | 295 | 55 | 425 | - | 5.6 |
